ADI集成VCO的锁相环
发布时间：2024-02-29 17:05:56 浏览：687
ADI集成VCO的锁相环适合于通信网络(COMMS)测试和检测(ETM)和航天工程/军事安全(ADEF)应用系统提供本振振荡器和时钟源。ADI集成VCO的锁相环包含窄带和宽带器件，同时支持13.6GHz的频率。ADI集成VCO的锁相环以及ADI全线产品PLL产品包括整数N分频PLL和小数N分频PLL具有优异的噪声系数性能、震动和杂散性能和高集成度都可以在中小型封装中实现。
深圳市立维创展科技是ADI的经销商。ADI芯片产品供应：放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤和光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处置器和DSP、射频和图形处置器、开关和分路器等。
大部分产品，均提供现货库存供货。
*部分型号需申请出口许可
欢迎咨询！！！
产品型号 | Freq Response RF (min) | Freq Response RF (max) | Freq Ref Input (max) | PFD (max) | FOM-Normalized Inband PN Int-N (typ) | FOM-Normalized inband PN Frac-N (typ) | 1/f Noise (10kHz Offset at 1GHz Carrier) (typ) | Pout RF Max (typ) | Is (typ) | Vs+ (min) | Vs+ (max) |
| Hz | Hz | Hz | Hz | dBc/Hz | dBc/Hz | dBc/Hz | dBm | A | V | V |
LTC6948-1 | 370M | 3.74G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-2 | 510M | 4.91G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-3 | 640M | 5.79G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-4 | 700M | 6.39G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
AD809 | 155.5M | 155.5M | 19.44M |
|
|
|
|
| 17m | 4.5 | 5.5 |
ADF4350 | 137.5M | 4.4G | 250M | 32M | -220 | -220 | -111 | 5 | 110m | 3 | 3.6 |
ADF4351 | 35M | 4.4G | 250M | 32M | -221 | -221 | -118 | 5 | 110m | 3 | 3.6 |
ADF4355 | 53.125M | 6.8G | 600M | 125M | -223 | -222 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF4355-2 | 53.125M | 4.4G | 600M | 125M | -223 | -222 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF4355-3 | 51.565M | 6.6G | 600M | 125M | -223 | -222 | -116 | 8 | 146m | 3.1515 | 3.4485 |
ADF4356 | 53.125M | 6.8G | 600M | 125M | -227 | -225 | -121 | 4 | 166m | 3.15 | 3.45 |
ADF4360-0 | 2.4G | 2.725G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-1 | 2.05G | 2.45G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-2 | 1.85G | 2.17G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-3 | 1.6G | 1.95G | 250M | 8M | -216 |
|
| -12 | 35m | 3 | 3.6 |
ADF4360-4 | 1.45G | 1.75G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-5 | 1.2G | 1.4G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-6 | 1.05G | 1.25G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-7 | 350M | 1.8G | 250M | 8M | -216 |
|
| -14 | 37.5m | 3 | 3.6 |
ADF4360-8 | 65M | 400M | 250M | 8M | -216 |
|
| -14 | 35m | 3 | 3.6 |
ADF4360-9 | 2M | 200M | 250M | 8M | -218 |
|
| -14 | 23m | 3 | 3.6 |
ADF4368 | 800M | 12.8G | 250M | 625M | -239 | -237 | -147 | 9 |
|
| 5.5 |
ADF4371 | 62.5M | 32G | 600M | 250M | -234 | -233 | -127 | 7 | 260m | 3.15 | 3.45 |
ADF4372 | 62M | 16G | 600M | 250M | -234 | -233 | -127 | 7 | 270M | 3.15 | 3.45 |
ADF4377 | 800M | 12.8G | 1G | 500M | -239 |
| -147 |
|
|
|
|
ADF4378 | 800M | 12.8G | 1G | 500M | -239 |
| -147 |
|
|
|
|
ADF5355 | 54M | 13.6G | 600M | 125M | -223 | -221 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF5356 | 53.125M | 13.6G | 600M | 125M | -227 | -225 | -121 | 4 | 126m | 3.15 | 5.25 |
HMC535 | 14.7G | 15.4G | 240.6M | 240.6M | -110 |
|
| 9 | 340m |
|
|
MAX2870 | 23.5M | 6G | 200M | 105M |
|
|
| 5 | 144m | 3 | 3.6 |
MAX2871 | 23.5M | 6G | 210M | 140M |
|
|
| 5 | 165m | 3 | 3.6 |
MAX2880 | 250M | 12.4G | 210M | 140M |
|
|
|
| 49m | 3 | 3.6 |
MAX9491 | 4M | 200M |
|
|
|
|
|
| 10m | 3 | 3.6 |
