ADI带输出分频器的压控振荡器(VCO)
发布时间：2022-12-09 16:47:20 浏览：6490
ADI提供各种带输出分压器选择的GaAsinGaP异质结双极性晶体管(HBT)MMICVCO，满足用户的应用与设计需求。ADI带输出分频器的压控振荡器(VCO)中的集成化谐振器、负变阻器件和变容二极管，都具备优异的相位噪声性能指标。
应用：
•点到点及点到多点无线通信
•检测设备和工业控制系统
•SATCOM
•VSAT
•军工用最终用途
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。大部分产品，均提供现货库存供货。
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
产品型号 | Freq Response RF (min) | Freq Response RF (max) | Freq Output Divider (min) | Freq Output Divider (max) | Phase Noise @ 10k | Phase Noise @ 100k | Output Power (typ) | Vtune (min) | Vtune (max) | Vs (typ) | Is (typ) |
| Hz | Hz | Hz | Hz | dBc/Hz | dBc/Hz |
| V | V | V | A |
HMC1163 | 9.65G | 10.41G | 4.825G | 5.205G | -87 | -114 | 11 dBm | 2 | 13 | 5 | 205m |
HMC1168 | 12.47G | 13.72G | 6.235G | 6.86G | -85 | -113 | 10 dBm | 2 | 13 | 5 | 190m |
HMC1169 | 12.92G | 14.07G | 6.46G | 7.035G | -86 | -113 | 11 dBm | 2 | 13 | 5 | 220m |
HMC1166 | 11.41G | 12.62G | 5.705G | 6.31G | -89 | -115 | 11 dBm | 2 | 13 | 5 | 220m |
HMC1167 | 12.17G | 13.3G | 6.085G | 6.65G | -86 | -113 | 10 dBm | 2 | 13 | 5 | 200m |
HMC1161 | 8.71G | 9.55G | 4.355G | 4.775G | -90 | -115 | 11 dBm | 2 | 13 | 5 | 250m |
HMC1165 | 11.07G | 11.62G | 5.535G | 5.81G | -88 | -113 | 8 dBm | 2 | 13 | 5 | 210m |
HMC1164 | 10.38G | 11.3G | 5.19G | 5.65G | -86 | -114 | 8 dBm | 2 | 13 | 5 | 200m |
HMC1160 | 8.45G | 9.3G | 4.225G | 4.65G | -90 | -116 | 12 dBm | 2 | 13 | 5 | 260m |
HMC1162 | 9.25G | 10.1G | 4.625G | 5.05G | -86 | -115 | 11 dBm | 2 | 13 | 5 | 230m |
HMC734 | 8.6G | 10.2G | 2.15G | 2.55G | -70 | -100 | 18 dBm | 1 | 13 | 5 | 218m |
HMC735 | 10.5G | 12.2G | 2.625G | 3.05G | -75 | -100 | 17 dBm | 1 | 13 | 5 | 217m |
HMC736 | 14.5G | 15G | 7.25G | 7.5G | -80 | -105 | 9 dBm | 1 | 13 | 4.2 | 150m |
HMC737 | 14.9G | 15.5G | 7.45G | 7.75G | -80 | -105 | 9 dBm | 1 | 13 | 4.2 | 150m |
HMC738 | 20.9G | 23.9G | 10.45G | 11.95G | -65 | -95 | 9 dBm | 1 | 13 | 5 | 200m |
HMC739 | 23.8G | 26.8G | 11.9G | 13.4G | -64 | -93 | 8 dBm | 1 | 13 | 5 | 200m |
HMC512 | 9.6G | 10.8G | 4.8G | 5.4G | -85 | -111 | 9 dBm | 2 | 13 | 5 | 330m |
HMC530 | 9.5G | 10.8G | 4.75G | 5.4G | -85 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC582 | 11.1G | 12.4G | 5.55G | 6.2G | -83 | -110 | 9 dBm | 2 | 13 | 5 | 350m |
HMC632 | 14.25G | 15.65G | 7.125G | 7.825G | -80 | -107 | 9 dBm | 2 | 13 | 5 | 350m |
HMC507 | 6.65G | 7.65G | 3.325G | 3.825G | -90 | -115 | 13 dBm | 2 | 13 | 5 | 230m |
HMC508 | 7.3G | 8.2G | 3.65G | 4.1G | -90 | -116 | 15 dBm | 2 | 13 | 5 | 240m |
HMC509 | 7.8G | 8.8G | 3.9G | 4.4G | -90 | -115 | 13 dBm | 2 | 13 | 5 | 250m |
HMC510 | 8.45G | 9.55G | 4.225G | 4.775G | -92 | -116 | 13 dBm | 2 | 13 | 5 | 315m |
HMC511 | 9.05G | 10.15G | 4.525G | 5.075G | -88 | -115 | 13 dBm | 2 | 13 | 5 | 265m |
HMC534 | 10.6G | 11.8G | 5.3G | 5.9G | -82 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC583 | 11.5G | 12.8G | 5.75G | 6.4G | -80 | -110 | 11 dBm | 2 | 13 | 5 | 350m |
HMC584 | 12.5G | 13.9G | 6.25G | 6.95G | -81 | -110 | 10 dBm | 2 | 13 | 5 | 330m |
HMC513 | 10.43G | 11.46G | 5.215G | 5.73G | -85 | -110 | 7 dBm | 2 | 13 | 5 | 275m |
HMC514 | 11.17G | 12.02G | 5.585G | 6.01G | -87 | -110 | 7 dBm | 2 | 13 | 3 | 275m |
HMC515 | 11.5G | 12.5G | 5.75G | 6.25G | -83 | -110 | 10 dBm | 2 | 13 | 5 | 200m |
HMC529 | 12.4G | 13.4G | 6.2G | 6.7G | -83 | -110 | 8 dBm | 2 | 13 | 5 | 260m |
HMC531 | 13.6G | 14.9G | 6.8G | 7.45G | -81 | -110 | 10 dBm | 2 | 13 | 5 | 330m |
HMC533 | 23.8G | 24.8G | 1.4875G | 1.55G | -70 | -95 | 12 dBm | 1 | 13 | 5 | 220m |
