ADI宽带分布式放大器
发布时间：2022-11-29 16:56:55 浏览：1680
ADI根据GaAs MMIC宽带分布式放大器包含多种超宽频宽DC至65GHz工作频段。ADI的设计产品分类包含低噪声放大器、功率放大器和驱动放大器。能够满足客户在电子战、雷达、电子对抗、光学应用和仪器设备应用中的需求。部分为了实现多种设计需求，LNA内部自偏置也能够提供，只需要一个信号渗漏电压就可以工作。
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。大部分产品，均提供现货库存供货。
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
产品型号 | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | OP1dB (typ) | OIP3 (typ) | NF (typ) | Vs (typ) | Is (typ) |
| Hz | Hz | dB | dBm | dBm | dB | V | A |
ADPA7009-2 | 20G | 54G | 17 | 26.5 | 34.5 | 7 | 5 | 850m |
ADL8106ACEZ | 18G | 54G | 21.5 | 14.5 | 21.5 | 3.5 | 3 | 120m |
ADL8106CHIPS | 20G | 54G | 21.5 | 14 | 21.5 | 3 | 3 | 120m |
ADPA7005-Die | 20G | 44G | 17 | 31 | 41 | 7 | 5 | 1.2 |
ADPA7005AEHZ | 18G | 44G | 15.5 | 31 | 40 | 7 | 5 | 1.4 |
ADCA3270 | 45M | 1.218G | 25 |
|
| 4 | 24 | 480m |
ADPA7008-Die | 20G | 54G | 18 | 30.5 | 38 | 6 | 5 | 1.5 |
ADPA7008AEHZ | 20G | 54G | 17.5 | 30 | 37 | 7 | 5 | 1.5 |
ADCA3950 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADCA3952 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADPA7009-Die | 20G | 54G | 19.5 | 28.5 | 35 | 5.5 | 5 | 750m |
ADPA7002-Die | 20G | 44G | 15 | 31 | 41 | 5.5 | 5 | 600m |
ADPA7002AEHZ | 18G | 44G | 17 | 28 | 38 | 5.8 | 5 | 700m |
ADPA7006-Die | 18G | 44G | 22.5 | 26 | 34 | 9.5 | 5 | 800m |
ADPA7006AEHZ | 18G | 44G | 23 | 29 | 37.5 | 7 | 5 | 800m |
ADPA7007-Die | 18G | 44G | 21.5 | 31 | 41 | 5.5 | 5 | 1.4 |
ADPA7007AEHZ | 20G | 44G | 21.5 | 30 | 42.5 | 5.5 | 5 | 1.4 |
ADCA3990 | 45M | 1.218G | 24.5 |
|
| 4 | 34 | 535m |
ADCA3992 | 45M | 1.218G | 26 |
|
| 4 | 34 | 535m |
HMC1022A-Die | 0 | 48G | 11.5 | 21 | 29 |
| 10 | 150m |
ADPA7004-Die | 40G | 80G | 18.5 | 22 | 31 |
| 3.5 | 550 |
HMC998A-Die | 0 | 22G | 14.5 | 32.5 | 43 | 2.5 | 15 | 500m |
HMC998ALP5E | 0.1G | 20G | 11 | 31 | 41 |
| 15 | 500m |
HMC998APM5E | 0 | 22G | 15 | 32 | 42 | 3 | 15 | 500m |
ADL9005 | 10M | 26.5G | 18.5 | 13.5 | 25 | 2.5 | 5 | 80m |
ADL9006-Die | 2G | 28G | 15.5 | 17 | 21 | 2.5 | 5 | 55 |
ADL9006ACGZN | 2G | 28G | 15.5 | 18 | 23 | 2.5 | 5 | 53m |
HMC637BPM5E | 0 | 7.5G | 15.5 | 28 | 39 | 3.5 | 12 | 345m |
ADPA7001-Die | 50G | 95G | 14.5 | 17 | 25.5 |
| 3.5 | 350m |
HMC907A-Die | 200M | 22G | 13.5 | 28.5 | 41 | 3 | 10 | 350m |
HMC907ALP5E | 200M | 22G | 13 | 28 | 40 | 3 | 10 | 350m |
HMC907APM5E | 200M | 22G | 13 | 28 | 40 | 3 | 10 | 350m |
ADL7003 | 50G | 95G | 14 | 14 | 21 | 5.5 | 3 | 120m |
HMC797A-Die | 0 | 22G | 15 | 29 | 41 | 3 | 10 | 400m |
HMC797ALP5E | 0 | 22G | 15 | 29 | 41 | 3.5 | 10 | 400m |
HMC797APM5E | 0 | 22G | 15 | 29 | 41 | 3.5 | 10 | 400m |
HMC994A-Die | 0 | 30G | 15 | 28 | 36 | 3 | 10 | 250m |
HMC994APM5E | 0 | 28G | 15 | 28 | 38 | 3.5 | 10 | 250m |
HMC5805A | 0 | 40G | 11.5 | 24.5 | 29 | 4 | 10 | 175m |
HMC7950 | 2G | 28G | 15 | 16 | 26 | 2 | 5 | 64m |
HMC930A-Die | 0 | 40G | 13 | 22 | 33.5 | 5 | 10 | 175m |
HMC1144-Die | 35G | 70G | 19 | 19.5 | 28 |
| 4 | 320m |
HMC1127 | 2G | 50G | 14 | 12 | 22 | 6 | 5 | 65m |
HMC1126 | 400M | 52G | 12 | 17.5 | 28.5 | 3.5 | 5 | 85m |
HMC1126-Die | 2G | 50G | 11 | 17.5 | 28 | 4.5 | 5 | 85m |
HMC637A-Die | 0G | 6G | 15.5 | 30.5 | 43 | 4 | 12 | 400m |
HMC637ALP5 | 0G | 6G | 15.5 | 29 | 44 | 5 | 12 | 400m |
HMC1049-Die | 0.3G | 20G | 16 | 13 | 25 | 2 | 7 | 70m |
HMC1049LP5E | 0.3G | 20G | 15 | 14.5 | 29 | 1.8 | 7 | 70m |
HMC1040-Die | 20G | 44G | 21 | 14 | 25.5 | 2.5 | 2.5 | 65m |
HMC1040LP3CE | 24G | 43.5G | 20 | 12 | 24 | 2.7 |
| 70m |
HMC962 | 7.5G | 26.5G | 13 | 12 | 23 | 2.5 | 3.5 | 70m |
HMC963 | 6G | 26.5G | 22 | 10 | 18 | 2.5 | 3.5 | 45m |
HMC633-Die | 5G | 17G | 29 | 23 | 30 | 7 | 5 | 180m |
HMC633LC4 | 5.5G | 17G | 30 | 23 | 30 | 10 | 5 | 180m |
HMC634-Die | 5G | 20G | 22 | 23 | 31 | 7 | 5 | 180m |
HMC634LC4 | 5G | 20G | 21 | 22 | 29 | 7.5 | 5 | 180m |
HMC635-Die | 18G | 40G | 19.5 | 23 | 29 | 8 | 5 | 280m |
HMC635LC4 | 18G | 40G | 18.5 | 22 | 27 | 7 | 5 | 280m |
HMC-ALH102-Die | 2G | 20G | 10 | 10 |
| 2.5 | 2 | 55m |
HMC-ALH482-Die | 2G | 22G | 16 | 14 |
| 1.7 | 4 | 45m |
HMC-AUH232-Die | 0 | 43G | 14 | 16.5 |
| 4.2 | 5 | 180m |
HMC-AUH249-Die | 0 | 35G | 15 | 21 |
|
| 5 | 200m |
HMC-AUH312-Die | 0.5G | 80G | 10 | 13.5 | 23 | 5 | 8 | 60m |
HMC606-Die | 2G | 18G | 12.5 | 13 | 22 | 6.5 | 5 | 64m |
HMC606LC5 | 2G | 18G | 12.5 | 13 | 22 | 7 | 5 | 64m |
HMC659-Die | 0G | 15G | 19 | 26.5 | 32 | 2 | 8 | 300m |
HMC659LC5 | 0 | 15G | 19 | 27.5 | 32 | 2.5 | 8 | 300m |
HMC559-Die | 0 | 20G | 14 | 27.5 | 36 | 3.5 | 10 | 400m |
HMC562-Die | 2G | 35G | 12.5 | 18 | 27 | 3 | 8 | 80m |
HMC459-Die | 0 | 18G | 17 | 25 | 31.5 | 3 | 8 | 290m |
HMC460-Die | 0G | 20G | 14 | 16 | 28 | 2.5 | 8 | 75m |
HMC460LC5 | 0 | 20G | 14 | 16 | 29 | 2.5 | 8 | 75m |
HMC462-Die | 2G | 20G | 15 | 14.5 | 25 | 2.5 | 5 | 63m |
HMC462LP5 | 2G | 20G | 13 | 14 | 25 | 2.5 | 5 | 66m |
HMC463-Die | 2G | 20G | 14 | 16 | 28 | 2.5 | 5 | 60m |
HMC463LH250 | 2G | 20G | 14 | 18 | 27 | 2.5 | 5 | 60m |
HMC463LP5 | 2G | 20G | 13 | 16 | 24 | 3 | 5 | 60m |
HMC464-Die | 2G | 20G | 16 | 26 | 30 | 4 | 8 | 290m |
HMC464LP5 | 2G | 20G | 14 | 25 | 26 | 4 | 8 | 290m |
HMC465-Die | 0G | 20G | 17 | 22 | 30 | 2.5 | 8 | 160m |
HMC465LP5 | 0 | 20G | 15 | 23 | 28 | 3 | 8 | 160m |
