ADI功率放大器

发布时间：2022-11-16 16:51:30 浏览：724

ADI的功率放大器根据GaN和GaAs半导体技术，工作频段从千赫兹到95GHz。除去裸片和贴纸器件，ADI的产品生产线还包括根据gan的功率放大器模块，输出功率超出8KW。ADI的功率放大器设计优异，在高输出功率下具备良好的线性度，并在各类有线和无线应用的受热情况下建立良好的散热和高可靠性。许多功率放大器包含十倍带宽，并且支持集成一个单一的集成电路，适用于仪表设备和国防军事应用。一些支持电信和卫星通讯的窄带产品也可以选择。有非常多的产品选择，能够为特殊的应用选择正确的产品。

ADI公司是模拟芯片、混合信号和数字信号处理技术方向的世界领先的品牌，ADI是高性能模拟芯片、混合信号处理器和数字信号分析处理(DSP)和集成电路(IC)设计、生产制造和产品营销方面处于世界领先水平的企业，ADI产品涉及到几乎所有的类型的电子行业以及电器行业设备，ADI产品应用于航空航天、工业、汽车、通信和消费电子市场。2017年ADI收购Hittite微波与毫米波产品线。

深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。大部分产品，均提供现货库存供货。

详情了解ADI请点击：http://www.leadwaytk.com/brand/34.html

1 (21).png

产品型号	Freq Response RF (min)	Freq Response RF (max)	Gain dB (typ)	OP1dB (typ)	OIP3 (typ)	Psat (typ)	Vs (typ)
	Hz	Hz	dB	dBm	dBm	dBm	V
ADPA7009-2	20G	54G	17	26.5	34.5	27.5	5
ADPA1106	2.7G	3.5G	34.5			46	50
ADPA7005-Die	20G	44G	17	31	41	32	5
ADPA7005AEHZ	18G	44G	15.5	31	40	32	5
ADCA3270	45M	1.218G	25				24
ADPA1107	4.8G	6G	30.5			45.5	28
ADPA7008-Die	20G	54G	18	30.5	38	31	5
ADPA7008AEHZ	20G	54G	17.5	30	37	31	5
ADCA3950	45M	1.218G	25				24
ADCA3952	45M	1.218G	25				24
ADPA7009-Die	20G	54G	19.5	28.5	35	29	5
ADPA1105	900M	1.6G	34.5			46	50
ADPA9002	0	10G	15.5	28	40.5	31	12
ADPA7002-Die	20G	44G	15	31	41	28.5	5
ADPA7002AEHZ	18G	44G	17	28	38	29.5	5
ADPA7006-Die	18G	44G	22.5	26	34	27	5
ADPA7006AEHZ	18G	44G	23	29	37.5	29	5
ADPA7007-Die	18G	44G	21.5	31	41	32	5
ADPA7007AEHZ	20G	44G	21.5	30	42.5	31.5	5
ADCA3990	45M	1.218G	24.5				34
ADCA3992	45M	1.218G	26				34
ADTR1107	6G	18G	17	23.9	30.9	25.3	5
ADMV7710	71G	76G	24	28	34	29	4
ADMV7810	81G	86G	20	28	33	29	4
ADPA7004-Die	40G	80G	18.5	22	31	24	3.5
HMC998A-Die	0	22G	14.5	32.5	43	33.5	15
HMC998ALP5E	0.1G	20G	11	31	41	33	15
HMC998APM5E	0	22G	15	32	42	34	15
HMC637BPM5E	0	7.5G	15.5	28	39	30	12
HMC863ALC4	24G	29.5G	24	27	38.5	28.5	5.5
ADPA7001-Die	50G	95G	14.5	17	25.5	21	3.5
HMC8415	9G	10.5G	32.5	35		46	28
HMC8205BCHIPS	400M	6G	26.5				50
HMC8205BF	300M	6G	28			46	50
HMC907A-Die	200M	22G	13.5	28.5	41	30	10
HMC907ALP5E	200M	22G	13	28	40		10
HMC907APM5E	200M	22G	13	28	40	28.5	10
HMC797A-Die	0	22G	15	29	41	31	10
HMC797ALP5E	0	22G	15	29	41		10
HMC797APM5E	0	22G	15	29	41	31	10
HMC906A-DIE	27.3G	33.5G	26.5	33.5	43	34	6
HMC943APM5E	24G	34G	23	33	37.5	34	5.5
HMC994A-Die	0	30G	15	28	36	30	10
HMC994APM5E	0	28G	15	28	38	29.5	10
HMC5805A	0	40G	11.5	24.5	29	27	10
HMC7885	2G	6G	21	39	53	45	28
HMC8500PM5E	10M	2.8G	15	32	47	40	28
HMC1114LP5DE	2.7G	3.8G	35	34	44	41.5	28
HMC1114PM5E	2.7G	3.8G	34.5	41.5	44		28
HMC8114	5.8G	18G	68	45	52	49.3	48
HMC1121	5.5G	8.5G	27	36	43	36.5	7
HMC1132PM5E	27G	32G	24	29	37	29.5	5
HMC8113	2G	6G	85	47.5	57	57	220
HMC952A	8G	14G	30.5	33	43	35	6
HMC1099LP5DE	10M	1.1G	19	40	49	40.5	28
HMC1099PM5E	10M	1.1G	18	30	47.5	41	28
HMC930A-Die	0	40G	13	22	33.5	24	10
HMC1144-Die	35G	70G	19	19.5	28	21.5	4
HMC7543	71G	76G	21.5	25	30	26.5	4
HMC8142	81G	86G	21	25	29	26	4
HMC7229-Die	33G	40G	24.5	30.5	39	31	6
HMC7229LS6	37G	40G	24	31.5	40	32	6
HMC637A-Die	0G	6G	15.5	30.5	43	31.5	12
HMC637ALP5	0G	6G	15.5	29	44	31	12
HMC7149-Die	6G	18G	19		39.5	40	28
HMC7441	27.5G	31G	23	34	38	34	6
HMC1086-Die	2G	6G	23		48	45	28
HMC1086F10	2G	6G	22		46	44.5	28
HMC1087-Die	2G	20G	11		44	40	28
HMC1087F10	2G	20G	11		42.5	38.5	38
HMC7357	5.5G	8.5G	29	34.5	41.5	35	8
HMC7054	29G	31G	42	38.5	47.5		5
HMC6981	15G	20G	26	33.5	43.5	34.5	6
HMC-APH460-Die	27G	31.5G	14	28	37	30	5
HMC-APH462-Die	15G	27G	17	29	37		5
HMC-APH473-Die	37G	40G	15	28	37		5
HMC-APH518-Die	21G	24G	17	30.5	39		5
HMC-APH608-Die	22.5G	26.5G	17	30	39		5
HMC590-Die	6G	10G	25	30	41	31.5	7
HMC590LP5	6G	9.5G	21	30.5	40	31	7
HMC591-Die	6G	10G	23	33	43	33.5	7
HMC591LP5	6G	9.5G	18	33	41	33	7
HMC659-Die	0G	15G	19	26.5	32	27	8
HMC659LC5	0	15G	19	27.5	32	28.5	8
HMC559-Die	0	20G	14	27.5	36	29	10
HMC409	3.3G	3.8G	31	30.5	45.5	32.5	5
HMC452QS16G	0.4G	2.17G	22.5	30	48	31	5
HMC452ST89	0.4G	2.17G	21	30.5	47	31.5	5
HMC453QS16G	400M	2.17G	21.5	32	49	32.5	5
HMC453ST89	0.4G	2.17G	20.5	31.5	47	31.75	5
HMC457	1.71G	2.17G	27	30.5	45	32	5
HMC459-Die	0	18G	17	25	31.5	26.5	8
HMC487	9G	12G	20	32	36	33	7
HMC454	824M	2.2G	12.5	27	41	28.5	5
HMC464-Die	2G	20G	16	26	30	27.5	8
HMC464LP5	2G	20G	14	25	26	26	8
HMC499-Die	21G	32G	16	24	33	24.5	5
HMC499LC4	21G	32G	17	23	34	23.5	5
HMC408	5.1G	5.9G	20	30	43	32.5	5
HMC455	1.7G	2.5G	13	27.5	42	28	5
HMC461	1.7G	2.2G	12	29.5	45	30.5	5
HMC327	3G	4G	21	27	40	30	5
HMC413	1.6G	2.2G	22	27	40	29.5	3.6
HMC414	2.2G	2.8G	20	27	39	30	5
