KR Electronics带通SMA连接器
发布时间：2023-08-31 16:37:54 浏览：892
带通滤波器是种可以通过相应频率范围内信号的滤波器，并将其频率范围内信号通过，从而把其它频率范围内信号衰减掉。KR Electronics带通SMA连接器是种广泛使用的中小型螺纹连接的同轴连接器，具备频率段宽.性能优.高可靠性.使用寿命长的特性。KR Electronics带通SMA连接器主要用于射频微波和数字通信系统的射频电路中连接射频同轴电缆或微带天线。
KR Electronics是美国一家资深射频滤波器设计公司，服务于军工与商业市场。其滤波器产品Bandpass Filter(带通滤波器）、Highpass Filters(高通滤波器）、Lowpass Filters（低通滤波器）、Root Cosine Filters(根余弦滤波器)、Notch Filters(陷波滤波器)、Diplexer Filters（双工滤波器）、Equalizers(平衡滤波器）等，产品特色以极低频率和优秀参数著称。
深圳市立维创展科技有限公司，授权代理销售KR Electronics滤波器产品。并提供售前和售后技术支持服务。
详情了解KR Electronics请点击：http://www.leadwaytk.com/brand/71.html
Part Number | Center
Frequency | Passband
Bandwidth | Passband
Attenuation
(dB) | Stopband
Bandwidth | Stopband
Attenuation
(dB) | Case
Style |
2480 | 18 KHz | 3.6 KHz | 2 | 7.2 KHz | 28 | SMA |
3372-39-SMA | 39 KHz | 4.7 KHz | 1 | 15 KHz | 40 | SMA |
2436-90-SMA | 90 KHz | 12 KHz | 1.5 | 28 KHz | 50 | SMA |
3317-SMA | 100 KHz | 5 KHz | 3 | 52 KHz | 60 | SMA |
3113 | 100 KHz | 5 KHz | 3 | 55 KHz | 60 | SMA |
2481 | 148 KHz | 3 KHz | 0.1 | 14.8 KHz | 20 | SMA |
3372-150-SMA | 150 KHz | 20 KHz | 1 | 70 KHz | 40 | SMA |
3372-195-SMA | 195 KHz | 20 KHz | 1 | 55 KHz | 40 | SMA |
3372-250-SMA | 250 KHz | 20 KHz | 1 | 65 KHz | 40 | SMA |
3372-395-SMA | 395 KHz | 20 KHz | 1 | 66 KHz | 40 | SMA |
2482 | 450 KHz | 9 KHz | 0.2 | 45 KHz | 20 | SMA |
3149 | 1 MHz | 30 KHz | 3 | 94 KHz | 40 | SMA |
3219-SMA | 1 MHz | 100 KHz | 3 | 290 KHz | 40 | SMA |
3128 | 1 MHz | 200 KHz | 3 | 576 KHz | 40 | SMA |
2728 | 1 MHz | 200 KHz | 3 | 1.4 MHz | 40 | SMA |
2521-1 | 1.1875 MHz | 237 KHz | 3 |
|
| SMA |
3464-SMA-MF | 1.3 MHz | 1 MHz | 3 | 1.5 MHz | 50 | SMA |
2861 | 2.075 MHz | 50 KHz | 1 |
| 100 | SMA |
3097-SMA | 2.5 MHz | 1.5 MHz | 3 | 3 MHz | 60 | SMA |
2970-SMA | 2.8 MHz | 425 KHz | 3 | 790 KHz | 50 | SMA |
3376-SMA | 4 MHz | 2.1 MHz | 3 | 6.83 MHz | 60 | SMA |
2427 | 4 MHz | 2 MHz | 3 | 5 MHz | 40 | SMA |
2859 | 4.15 MHz | 830 KHz | 3 | 3 MHz | 60 | SMA |
3131-4.23 | 4.23 MHz | 5.04 MHz | 1 | 9.86 MHz | 80 | SMA |
2322-50-SMA | 4.95 MHz | 1.23 MHz | 1.4 | 1.71 MHz | 45 | SMA |
2938 | 5 MHz | 370 KHz | 3 | 890 KHz | 40 | SMA |
2792-5-SMA | 5 MHz | 2.1 MHz | 3 | 6.3 MHz | 60 | SMA |
2521-2 | 5.8 MHz | 1.16 MHz | 3 |
|
| SMA |
2711 | 6 MHz | 4 MHz | 0.5 | 8 MHz | 50 | SMA |
2775 | 6 MHz | 8 MHz | 3 | 14.8 MHz | 60 | SMA |
2601 | 6 MHz | 1.8 MHz | 1 | 12 MHz | 80 | SMA |
2860 | 6.2 MHz | 1.24 MHz | 3 | 7 MHz | 60 | SMA |
3207-SMA | 7 MHz | 475 KHz | 3 | 2.2 MHz | 40 | SMA |
2710-7.8M-SMA | 7.8 MHz | 4 MHz | 3 |
| 65 | SMA |
2724 | 8 MHz | 800 KHz | 3 | 2.2 MHz | 40 | SMA |
2725 | 9 MHz | 900 KHz | 3 | 2.55 MHz | 40 | SMA |
3131-9.1 | 9.1 MHz | 5.1 MHz | 1 | 12.3 MHz | 80 | SMA |
2862 | 9.24 MHz | 2.1 MHz | 3 | 7.2 MHz | 100 | SMA |
2577 | 9.5 MHz | 475 KHz | 3 | 2.875 MHz | 50 | SMA |
2796-SMA | 10 MHz | 400 KHz | 3 | 2.15 MHz | 60 | SMA |
2588 | 10 MHz | 1 MHz | 3 | 2.45 MHz | 40 | SMA |
2588-1 | 10 MHz | 1 MHz | 3 | 2.55 MHz | 40 | SMA |
2589 | 10 MHz | 2 MHz | 3 | 5 MHz | 55 | SMA |
2712 | 10 MHz | 4 MHz | 0.5 | 9 MHz | 40 | SMA |
3158 | 10 MHz | 6.3 MHz | 3 | 15 MHz | 100 | SMA |
2157-10.5-5-50-SMA | 10.5 MHz | 540 KHz | 3 | 4.28 MHz | 40 | SMA |
2842 | 10.5 MHz | 1 MHz | 2 | 3 MHz | 60 | SMA |
2567 | 10.7 MHz | 6 MHz | 3 | 11.5 MHz | 60 | SMA |
2853 | 10.75 MHz | 7.5 MHz | 3 | 9.5 MHz | 35 | SMA |
3019 | 11.5 MHz | 400 KHz | 3 | 2.3 MHz | 60 | SMA |
3131-11.7 | 11.7 MHz | 20 MHz | 1 | 34 MHz | 80 | SMA |
3396-12.88-SMA | 12.88 MHz | 1.25 MHz | 3 | 6.7 MHz | 60 | SMA |
3396-13.56-SMA | 13.56 MHz | 1.28 MHz | 3 | 7 MHz | 60 | SMA |
2713 | 14 MHz | 4 MHz | 0.5 | 9.2 MHz | 40 | SMA |
3131-14 | 14 MHz | 5.1 MHz | 1 | 12.5 MHz | 80 | SMA |
3066 | 14 MHz | 13.5 MHz | 1 | 17 MHz | 35 | SMA |
2598 | 15 MHz | 2 MHz | 0.5 | 12 MHz | 40 | SMA |
3155-SMA | 16 MHz | 4 MHz | 3 | 10 MHz | 40 | SMA |
3131-16.6 | 16.6 MHz | 29.84 MHz | 1 | 49.67 MHz | 80 | SMA |
3118 | 17.5 MHz | 1 MHz | 3 | 2.8 MHz | 40 | SMA |
3131-17.5 | 17.5 MHz | 28 MHz | 1 | 48.8 MHz | 80 | SMA |
2939 | 18 MHz | 1.35 MHz | 3 | 3.25 MHz | 40 | SMA |
2714 | 18 MHz | 4 MHz | 0.6 | 9.3 MHz | 40 | SMA |
3167-18.625 | 18.625 MHz | 1.5 MHz | 3 | 4 MHz | 40 | SMA |
3131-18.9 | 18.9 MHz | 5.1 MHz | 1 | 12.25 MHz | 80 | SMA |
3196-19-SMA | 19 MHz | 5 MHz | 3 | 15 MHz | 40 | SMA |
3167-19.5 | 19.5 MHz | 1.5 MHz | 3 | 4 MHz | 40 | SMA |
3200-SMA | 19.95 MHz | 600 KHz | 3 | 1100 KHz | 60 | SMA |
2574-SMA | 20 MHz | 5 MHz | 3 | 20 MHz | 40 | SMA |
3159 | 20 MHz | 8.5 MHz | 3 | 20 MHz | 100 | SMA |
2715 | 22 MHz | 4 MHz | 0.7 | 9.8 MHz | 40 | SMA |
3167-23.5 | 23.5 MHz | 1.5 MHz | 3 | 4 MHz | 40 | SMA |
3131-23.8 | 23.8 MHz | 5.1 MHz | 1 | 15.3 MHz | 80 | SMA |
3393-SMA | 24.25 MHz | 400 KHz | 3 | 1.32 MHz | 40 | SMA |
3167-24.5 | 24.5 MHz | 1.5 MHz | 3 | 4 MHz | 40 | SMA |
2474-D | 25 MHz | 3.6 MHz | 3 | 17 MHz | 60 | SMA |
3327-SMA | 25 MHz | 4 MHz | 3 | 6 MHz | 30 | SMA |
3260-25-BP-SMA | 25 MHz | 5 MHz | 3 | 34 MHz | 50 | SMA |
3196-25-SMA | 25 MHz | 5 MHz | 3 | 16 MHz | 40 | SMA |
2474-C | 25 MHz | 7.2 MHz | 3 | 14 MHz | 60 | SMA |
3367-SMA | 25 MHz | 12.5 MHz | 1 | 33 MHz | 50 | SMA |
3133 | 25 MHz | 44 MHz | 3 | 52 MHz | 20 | SMA |
3396-25.76-SMA | 25.76 MHz | 4.1 MHz | 3 | 28.6 MHz | 60 | SMA |
3146 | 26 MHz | 1.5 MHz | 3 | 3.95 MHz | 40 | SMA |
2716 | 26 MHz | 4 MHz | 0.7 | 10.5 MHz | 40 | SMA |
2473-B | 26.9 MHz | 3.95 MHz | 3 | 18.2 MHz | 60 | SMA |
2473-A | 26.9 MHz | 7.8 MHz | 3 | 15 MHz | 60 | SMA |
3424-27-SMA | 27 MHz | 1.5 MHz | 3 | 2.5 MHz | 40 | SMA |
2940 | 27 MHz | 1.5 MHz | 3 | 3.53 MHz | 40 | SMA |
3396-27.02-SMA | 27 MHz | 4.3 MHz | 3 | 21 MHz | 40 | SMA |
3131-28.7 | 28.7 MHz | 5.1 MHz | 1 | 14.9 MHz | 80 | SMA |
3371-SMA | 30 MHz | 2 MHz | 3 | 9.8 MHz | 40 | SMA |
2843 | 30 MHz | 3.2 MHz | 3 | 6 MHz | 40 | SMA |
3437-SMA | 30 MHz | 8 MHz | 3 | 17.2 MHz | 60 | SMA |
3433-31.25-SMA | 31.25 MHz | 2 MHz | 3 | 7.9 MHz | 40 | SMA |
2726 | 32 MHz | 3.2 MHz | 3 | 9 MHz | 40 | SMA |
2492 | 32.5 MHz | 35 MHz | 1 |
|
| SMA |
3447-34-SMA | 34 MHz | 12 MHz | 1 | 31 MHz | 60 | SMA |
3038 | 35 MHz | 2 MHz | 3 | 7.2 MHz | 40 | SMA |
2936-2-SMA | 36 MHz | 8 MHz | 1 | 20.8 MHz | 50 | SMA |
3010-SMA | 37.5 MHz | 20 MHz | 3 | 30 MHz | 40 | SMA |
2510-SMA | 40 MHz | 4 MHz | 3 | 10 MHz | 55 | SMA |
3396-40.68-SMA | 40.68 MHz | 3.75 MHz | 3 | 22.5 MHz | 60 | SMA |
2801-SMA | 42 MHz | 4 MHz | 3 | 10 MHz | 55 | SMA |
3114-SMA | 43.75 MHz | 7 MHz | 3 | 16 MHz | 40 | SMA |
2742 | 44 MHz | 15 MHz | 3 | 44 MHz | 60 | SMA |
2590-1 | 45 MHz | 10 MHz | 1.5 | 52.5 MHz | 50 | SMA |
2339 | 45 MHz | 28 MHz | 3 | 42 MHz | 60 | SMA |
3333-SMA | 49.5 MHz | 1 MHz | 1 | 4.7 MHz | 40 | SMA |
2867 | 50 MHz | 9 MHz | 3 | 20 MHz | 60 | SMA |
3077-SMA | 50 MHz | 10 MHz | 3 | 24 MHz | 55 | SMA |
3267-SMA | 50 MHz | 99.9 MHz | 3 | 119.95 MHz | 40 | SMA |
2804-SMA | 53 MHz | 58 MHz | 2 | 93 MHz | 40 | SMA |
2590-2 | 53.9 MHz | 11.8 MHz | 1.5 | 68.2 MHz | 50 | SMA |
3236-SMA | 60 MHz | 8 MHz | 3 | 24 MHz | 40 | SMA |
2959 | 60 MHz | 9 MHz | 3 | 19 MHz | 40 | SMA |
2941-2 | 60 MHz | 20 MHz | 2 | 30 MHz | 60 | SMA |
2553 | 60 MHz | 26 MHz | 0.4 | 92 MHz | 60 | SMA |
2587-60 | 60 MHz | 30 MHz | 1 | 75 MHz | 55 | SMA |
2915 | 60 MHz | 36 MHz | 1 | 80 MHz | 60 | SMA |
2941-1 | 60 MHz | 40 MHz | 3 | 50 MHz | 40 | SMA |
2590-3 | 64.9 MHz | 14.2 MHz | 1.5 | 75.1 MHz | 50 | SMA |
2909 | 65 MHz | 1.6 MHz | 1 | 10 MHz | 50 | SMA |
2996 | 65 MHz | 4 MHz | 3 | 11.6 MHz | 40 | SMA |
2544 | 65 MHz | 10 MHz | 4 | 26 MHz | 65 | SMA |
3410-65-SMA | 65 MHz | 110 MHz | 3 | 131 MHz | 40 | SMA |
3386-SMA | 67 MHz | 7.7 MHz | 3 | 25 MHz | 40 | SMA |
3186-SMA | 69.12 MHz | 20 MHz | 1 | 32 MHz | 60 | SMA |
3324 | 70 MHz | 1 MHz | 3 | 4.63 MHz | 40 | SMA |
2962 | 70 MHz | 2 MHz | 3 | 7.4 MHz | 40 | SMA |
2997 | 70 MHz | 4 MHz | 3 | 11.4 MHz | 40 | SMA |
2657-SMA | 70 MHz | 5 MHz | 3 | 15.5 MHz | 40 | SMA |
2441 | 70 MHz | 7 MHz | 1 | 23 MHz | 55 | SMA |
2565 | 70 MHz | 8 MHz | 1 | 26 MHz | 55 | SMA |
2565-1 | 70 MHz | 8 MHz | 1 | 26 MHz | 55 | SMA |
2494 | 70 MHz | 9 MHz | 3 | 40 MHz | 50 | SMA |
2866-SMA | 70 MHz | 10 MHz | 3 | 32 MHz | 60 | SMA |
2925-SMA | 70 MHz | 15 MHz | 1 | 25 MHz | 35 | SMA |
3277-SMA | 70 MHz | 20 MHz | 3 | 40 MHz | 60 | SMA |
3011 | 70 MHz | 20 MHz | 1 | 80 MHz | 40 | SMA |
3127 | 70 MHz | 20 MHz | 1 | 80 MHz | 40 | SMA |
3480-70-SMA | 70 MHz | 24 MHz | 1 | 45 MHz | 40 | SMA |
2471 | 70 MHz | 25 MHz | 3 | 36 MHz | 30 | SMA |
3157-1 | 70 MHz | 30 MHz | 0.5 | 44 MHz | 40 | SMA |
2924-SMA | 70 MHz | 31 MHz | 1 | 49 MHz | 40 | SMA |
2993 | 70 MHz | 36 MHz | 3 | 45 MHz | 40 | SMA |
2477-SMA | 70 MHz | 36 MHz | 1 | 74 MHz | 55 | SMA |
2871-SMA | 70 MHz | 40 MHz | 4 | 46 MHz | 30 | SMA |
2810 | 70 MHz | 40 MHz | 3 | 60 MHz | 40 | SMA |
2757 | 70 MHz | 40 MHz | 1 | 80 MHz | 50 | SMA |
2818 | 70 MHz | 40 MHz | 0.25 | 97 MHz | 35 | SMA |
3169-SMA | 70 MHz | 60 MHz | 1 | 90 MHz | 50 | SMA |
2935 | 71 MHz | 36 MHz | 3 | 63 MHz | 70 | SMA |
3311-SMA | 74 MHz | 1.85 MHz | 1 | 9.4 MHz | 50 | SMA |
3297-SMA | 75 MHz | 10 MHz | 1 | 30 MHz | 50 | SMA |
2898 | 75 MHz | 16 MHz | 1 | 91 MHz | 40 | SMA |
2587-75 | 75 MHz | 30 MHz | 1 | 75 MHz | 55 | SMA |
2751-SMA | 77.76 MHz | 20 MHz | 4 | 34 MHz | 60 | SMA |
2752-SMA | 77.76 MHz | 25 MHz | 4 | 42.5 MHz | 60 | SMA |
2590-4 | 78.6 MHz | 17.2 MHz | 1.5 | 91 MHz | 50 | SMA |
3016 | 80 MHz | 4 MHz | 3 | 11 MHz | 40 | SMA |
2865 | 80 MHz | 12.5 MHz | 3 | 41 MHz | 60 | SMA |
2521-3 | 80 MHz | 16 MHz | 3 | 66 MHz | 60 | SMA |
2899 | 90 MHz | 20 MHz | 3 | 91 MHz | 40 | SMA |
2488 | 95 MHz | 30 MHz | 3 | 65 MHz | 60 | SMA |
2590-5 | 95.7 MHz | 21 MHz | 1.5 | 111 MHz | 50 | SMA |
3212-97.5-SMA | 97.5 MHz | 45 MHz | 1 | 187 MHz | 40 | SMA |
2722 | 98 MHz | 20 MHz | 3 | 40 MHz | 60 | SMA |
2618-3-SMA-1 | 100 MHz | 4 MHz | 1 | 40 MHz | 60 | SMA |
2618-3-SMA | 100 MHz | 4 MHz | 1 | 40 MHz | 60 | SMA |
2582 | 100 MHz | 20 MHz | 2 | 50 MHz | 58 | SMA |
2521-4 | 100 MHz | 20 MHz | 3 | 67.5 MHz | 50 | SMA |
2900 | 100 MHz | 21 MHz | 3 | 100 MHz | 40 | SMA |
2587-100 | 100 MHz | 30 MHz | 1 | 75 MHz | 55 | SMA |
2599 | 105 MHz | 10 MHz | 1 | 75 MHz | 50 | SMA |
3178-110 | 110 MHz | 9.5 MHz | 3 | 24.3 MHz | 40 | SMA |
2901 | 110 MHz | 21 MHz | 3 | 98 MHz | 40 | SMA |
3108 | 110 MHz | 200 MHz | 0.5 | 246 MHz | 50 | SMA |
3109 | 113 MHz | 16 MHz | 3 | 40 MHz | 40 | SMA |
2590-6 | 114 MHz | 25 MHz | 1.5 | 130.5 MHz | 50 | SMA |
2964-SMA | 115 MHz | 12.7 MHz | 3 | 40.9 MHz | 40 | SMA |
3178-120 | 120 MHz | 9.5 MHz | 3 | 24.6 MHz | 40 | SMA |
2600 | 120 MHz | 10 MHz | 1 | 75 MHz | 40 | SMA |
2779 | 120 MHz | 20 MHz | 3 | 60 MHz | 40 | SMA |
2887 | 123 MHz | 28 MHz | 3 | 67 MHz | 40 | SMA |
3194-SMA | 125 MHz | 6 MHz | 3 | 17.8 MHz | 50 | SMA |
2587-125 | 125 MHz | 30 MHz | 1 | 75 MHz | 55 | SMA |
2780 | 130 MHz | 20 MHz | 3 | 70 MHz | 40 | SMA |
2781 | 132 MHz | 20 MHz | 3 | 70 MHz | 40 | SMA |
3030-140-5-SMA | 140 MHz | 5 MHz | 1 | 53 MHz | 40 | SMA |
2771-SMA | 140 MHz | 6 MHz | 3 | 30 MHz | 40 | SMA |
2782 | 140 MHz | 20 MHz | 3 | 70 MHz | 40 | SMA |
3480-140-SMA | 140 MHz | 24 MHz | 1 | 56 MHz | 40 | SMA |
2905 | 140 MHz | 20 MHz | 0.5 | 90 MHz | 80 | SMA |
3132 | 140 MHz | 20 MHz | 0.5 | 90 MHz | 80 | SMA |
2838-30-SMA | 140 MHz | 30 MHz | 1.5 | 54 MHz | 40 | SMA |
2743 | 140 MHz | 56 MHz | 1 | 140 MHz | 50 | SMA |
2880 | 140 MHz | 60 MHz | 2 | 144 MHz | 50 | SMA |
2903 | 140 MHz | 80 MHz | 2 | 145 MHz | 40 | SMA |
3029 | 140 MHz | 90 MHz | 3 | 130 MHz | 50 | SMA |
3215-SMA | 141 MHz | 66 MHz | 1 | 145 MHz | 50 | SMA |
2783 | 150 MHz | 20 MHz | 3 | 75 MHz | 40 | SMA |
3049 | 150 MHz | 20 MHz | 3 | 40 MHz | 50 | SMA |
2877-SMA | 150 MHz | 80 MHz | 3 | 100 MHz | 35 | SMA |
2811 | 155 MHz | 40 MHz | 1.25 | 200 MHz | 40 | SMA |
3326-SMA | 156.25 MHz | 6 MHz | 1 | 40 MHz | 60 | SMA |
2746 | 157.5 MHz | 55 MHz | 3 | 85 MHz | 50 | SMA |
3172-SMA | 160 MHz | 10 MHz | 3 | 48 MHz | 60 | SMA |
2629-20 | 160 MHz | 20 MHz | 3 | 40 MHz | 50 | SMA |
2629-40 | 160 MHz | 40 MHz | 3 | 70 MHz | 50 | SMA |
3046 | 160 MHz | 50 MHz | 2 | 88 MHz | 50 | SMA |
2629-50 | 160 MHz | 50 MHz | 3 | 88 MHz | 50 | SMA |
2629-80 | 160 MHz | 80 MHz | 3 | 140 MHz | 50 | SMA |
2704-SMA | 160 MHz | 100 MHz | 0.35 | 400 MHz | 80 | SMA |
3183-SMA | 167 MHz | 10 MHz | 3 | 32 MHz | 40 | SMA |
3348-SMA | 172 MHz | 10 MHz | 3 | 34 MHz | 40 | SMA |
3179-SMA | 175 MHz | 35 MHz | 3 | 50 MHz | 50 | SMA |
2883 | 180 MHz | 20 MHz | 3 | 82 MHz | 60 | SMA |
3067-SMA | 184 MHz | 50 MHz | 1 | 122 MHz | 60 | SMA |
3310-187.5-SMA | 187.5 MHz | 45 MHz | 1 | 85 MHz | 30 | SMA |
3342-187.5-SMA | 187.5 MHz | 95 MHz | 3 | 320 MHz | 60 | SMA |
3268-100-SMA | 187.5 MHz | 100 MHz | 1 | 150 MHz | 15 | SMA |
3165-SMA | 189 MHz | 58 MHz | 2 | 95 MHz | 40 | SMA |
2825 | 196 MHz | 40 MHz | 3 | 82 MHz | 50 | SMA |
2800-SMA | 200 MHz | 6 MHz | 3 | 35 MHz | 40 | SMA |
3406-SMA-MF | 200 MHz | 34 MHz | 3 | 50 MHz | 50 | SMA |
2649 | 200 MHz | 40 MHz | 3 | 82 MHz | 50 | SMA |
2649-SMA-MF | 200 MHz | 40 MHz | 3 | 82 MHz | 50 | SMA |
3259-200-SMA | 200 MHz | 100 MHz | 2 | 200 MHz | 55 | SMA |
2932 | 210 MHz | 100 MHz | 3 | 400 MHz | 40 | SMA |
2892-SMA | 250 MHz | 50 MHz | 3 | 111 MHz | 40 | SMA |
2892-SMA-MF | 250 MHz | 50 MHz | 3 | 111 MHz | 40 | SMA |
3062 | 250 MHz | 70 MHz | 3 | 100 MHz | 40 | SMA |
3248-SMA | 250 MHz | 75 MHz | 3 | 102 MHz | 40 | SMA |
2943-SMA | 255 MHz | 30 MHz | 3 | 71 MHz | 40 | SMA |
3320-SMA | 256 MHz | 30 MHz | 2 | 71 MHz | 40 | SMA |
3032 | 281 MHz | 34 MHz | 3 | 63 MHz | 40 | SMA |
3218-300-SMA | 300 MHz | 40 MHz | 3 | 134 MHz | 35 | SMA |
2897-SMA | 300 MHz | 98 MHz | 1 | 155 MHz | 50 | SMA |
2979-SMA | 300 MHz | 150 MHz | 2 | 250 MHz | 65 | SMA |
3321-SMA | 304 MHz | 30 MHz | 2 | 78 MHz | 40 | SMA |
3334-SMA | 312.5 MHz | 25 MHz | 2 | 91 MHz | 60 | SMA |
3342-312-SMA | 312 MHz | 195 MHz | 3 | 585 MHz | 60 | SMA |
2986 | 320 MHz | 60 MHz | 1 | 116 MHz | 50 | SMA |
3235-SMA | 321.4 MHz | 60 MHz | 0.5 | 200 MHz | 60 | SMA |
3486-3-SMA | 325 MHz | 350 MHz | 1 | 925 MHz | 60 | SMA |
3410-330-SMA | 330 MHz | 440 MHz | 3 | 505 MHz | 40 | SMA |
3177-SMA | 332.5 MHz | 190 MHz | 3 | 215 MHz | 20 | SMA |
3390-SMA | 340 MHz | 15 MHz | 3 | 92 MHz | 60 | SMA |
3288-SMA | 350 MHz | 10 MHz | 3 | 150 MHz | 40 | SMA |
2456 | 350 MHz | 56 MHz | 3 | 160 MHz | 20 | SMA |
2874-SMA | 350 MHz | 50 MHz | 0.75 | 140 MHz | 40 | SMA |
3093-SMA | 350 MHz | 100 MHz | 1 | 200 MHz | 50 | SMA |
3218-360-SMA | 360 MHz | 20 MHz | 3 | 61 MHz | 35 | SMA |
3336-SMA | 365 MHz | 470 MHz | 1 | 653 MHz | 50 | SMA |
3397-SMA | 369 MHz | 25 MHz | 1 | 66 MHz | 40 | SMA |
3243-SMA | 374 MHz | 452 MHz | 1 | 640 MHz | 40 | SMA |
2784 | 375 MHz | 50 MHz | 3 | 240 MHz | 50 | SMA |
2975-SMA | 375 MHz | 200 MHz | 3 | 300 MHz | 65 | SMA |
2602-SMA | 400 MHz | 20 MHz | 3 | 300 MHz | 50 | SMA |
3208-SMA | 400 MHz | 29 MHz | 2 | 139 MHz | 50 | SMA |
3260-400-SMA | 400 MHz | 200 MHz | 2 | 400 MHz | 55 | SMA |
3292-SMA | 412.5 MHz | 45 MHz | 3 | 65 MHz | 25 | SMA |
3079-SMA | 425 MHz | 99 MHz | 3 | 214 MHz | 40 | SMA |
3181-SMA | 435 MHz | 120 MHz | 3 | 350 MHz | 30 | SMA |
2881-SMA | 440 MHz | 50 MHz | 3 | 127 MHz | 60 | SMA |
3458-SMA | 440 MHz | 80 MHz | 3 | 125 MHz | 60 | SMA |
3017-SMA | 455 MHz | 30 MHz | 3 | 94 MHz | 40 | SMA |
3353-SMA | 460 MHz | 28 MHz | 3 | 60 MHz | 80 | SMA |
2977-SMA | 485 MHz | 40 MHz | 2 | 117 MHz | 40 | SMA |
2963-SMA | 485 MHz | 60 MHz | 3 | 200 MHz | 40 | SMA |
2965-SMA | 500 MHz | 7 MHz | 1 | 51 MHz | 40 | SMA |
2659-SMA | 500 MHz | 24 MHz | 3 | 76 MHz | 40 | SMA |
3129 | 500 MHz | 200 MHz | 3 | 570 MHz | 40 | SMA |
3152-SMA | 520 MHz | 40 MHz | 3 | 105 MHz | 40 | SMA |
3342-525-SMA | 525 MHz | 270 MHz | 3 | 860 MHz | 60 | SMA |
3299-SMA | 530 MHz | 280 MHz | 1 | 450 MHz | 40 | SMA |
3299-SMA-F-F | 530 MHz | 280 MHz | 1 | 450 MHz | 40 | SMA |
2876 | 550 MHz | 55 MHz | 3 | 110 MHz | 60 | SMA |
2464 | 550 MHz | 102 MHz | 3 | 202 MHz | 50 | SMA |
3316-SMA | 550 MHz | 500 MHz | 1 | 766 MHz | 50 | SMA |
2648 | 585 MHz | 230 MHz | 3 | 460 MHz | 50 | SMA |
3130 | 600 MHz | 50 MHz | 3 | 105 MHz | 60 | SMA |
3392-SMA | 625 MHz | 300 MHz | 3 | 533 MHz | 50 | SMA |
3329-SMA | 650 MHz | 50 MHz | 3 | 100 MHz | 60 | SMA |
3325-SMA | 656.25 MHz | 10 MHz | 1 | 55 MHz | 40 | SMA |
3378-SMA | 720 MHz | 400 MHz | 3 | 540 MHz | 40 | SMA |
2855-SMA | 725 MHz | 350 MHz | 3 | 500 MHz | 40 | SMA |
2918 | 750 MHz | 40 MHz | 2 | 154 MHz | 20 | SMA |
3231-SMA | 750 MHz | 220 MHz | 3 | 939 MHz | 60 | SMA |
2829-SMA | 760 MHz | 50 MHz | 3 | 165 MHz | 20 | SMA |
3057-SMA | 795 MHz | 95 MHz | 3 | 294 MHz | 40 | SMA |
3477-860-SMA | 860 MHz | 100 MHz | 3 | 440 MHz | 60 | SMA |
3328-SMA | 865 MHz | 250 MHz | 3 | 600 MHz | 80 | SMA |
3306-869-430 | 869 MHz | 430 MHz | 3 | 634 MHz | 40 | SMA |
3242-SMA | 900 MHz | 620 MHz | 3 | 820 MHz | 40 | SMA |
3212-910-SMA | 910 MHz | 180 MHz | 1 | 890 MHz | 40 | SMA |
3078-950 | 950 MHz | 500 MHz | 1 | 865 MHz | 40 | SMA |
2803 | 975 MHz | 500 MHz | 3 | 1350 MHz | 40 | SMA |
3450-SMA | 1000 MHz | 50 MHz | 1 | 135 MHz | 40 | SMA |
3306-1000-90 | 1000 MHz | 114 MHz | 3 | 250 MHz | 60 | SMA |
2949-SMA | 1000 MHz | 500 MHz | 3 | 1400 MHz | 40 | SMA |
3356-SMA | 1000 MHz | 500 MHz | 1 | 832 MHz | 50 | SMA |
3409-SMA | 1000 MHz | 540 MHz | 3 | 700 MHz | 50 | SMA |
3306-1025-90 | 1025 MHz | 90 MHz | 1 | 246 MHz | 60 | SMA |
3323-SMA | 1087.5 MHz | 241 MHz | 3 | 350 MHz | 30 | SMA |
3204-SMA | 1087.5 MHz | 255 MHz | 3 | 582 MHz | 40 | SMA |
3379-SMA | 1200 MHz | 600 MHz | 3 | 1435 MHz | 40 | SMA |
2954-SMA | 1210 MHz | 507 MHz | 3 | 1215 MHz | 40 | SMA |
3402-SMA | 1225 MHz | 550 MHz | 3 | 650 MHz | 35 | SMA |
3486-4-SMA | 1250 MHz | 1500 MHz | 1 | 3750 MHz | 60 | SMA |
3273-SMA | 1425 MHz | 200 MHz | 1 | 684 MHz | 60 | SMA |
3078-1450 | 1450 MHz | 500 MHz | 3 | 930 MHz | 40 | SMA |
3160 | 1500 MHz | 96 MHz | 3 | 325 MHz | 40 | SMA |
3144 | 1500 MHz | 1200 MHz | 3 | 2500 MHz | 40 | SMA |
3192-2 | 1555 MHz | 2900 MHz | 3 | 3520 MHz | 45 | SMA |
3078-1600 | 1600 MHz | 600 MHz | 3 | 1346 MHz | 60 | SMA |
2958-SMA | 1630 MHz | 623 MHz | 3 | 1200 MHz | 40 | SMA |
3111 | 1642 MHz | 50 MHz | 3 | 164 MHz | 25 | SMA |
3340-SMA | 1700 MHz | 100 MHz | 3 | 438 MHz | 40 | SMA |
3125 | 1875 MHz | 600 MHz | 3 | 1420 MHz | 40 | SMA |
3078-1950 | 1950 MHz | 500 MHz | 3 | 1145 MHz | 40 | SMA |
3192-3 | 2000 MHz | 2000 MHz | 3 | 2685 MHz | 40 | SMA |
3078-2498 | 2498 MHz | 300 MHz | 3 | 626 MHz | 50 | SMA |
3078-2850 | 2850 MHz | 300 MHz | 3 | 690 MHz | 50 | SMA |
3078-2998 | 2998 MHz | 300 MHz | 3 | 770 MHz | 50 | SMA |
3126 | 3300 MHz | 2000 MHz | 3 | 3325 MHz | 40 | SMA |
3306-3381-1629 | 3381 MHz | 1629 MHz | 3 | 2425 MHz | 40 | SMA |
3306-3381-2100 | 3381 MHz | 2100 MHz | 3 | 3055 MHz | 40 | SMA |
3306-3397-1600 | 3397 MHz | 1600 MHz | 3 | 2450 MHz | 40 | SMA |
3229-SMA | 3500 MHz | 200 MHz | 3 | 615 MHz | 40 | SMA |
3486-1-SMA | 4325 MHz | 600 MHz | 1 | 2020 MHz | 40 | SMA |
