µModule 降压型稳压器LINEAR
发布时间：2022-08-19 16:15:18 浏览：1330
LINEAR的降压µModule®稳压器是完整的系统级封装(SiP)电源管理解决方案，搭载了DC-DC控制器，功率晶体管，输入和输出电容，补偿器件和电感器。µModule降压调节器适合于紧凑的表面贴装BGA或LGA封装。一些产品具备额外功能，如可调式电流限制，低EMIEN55022B级合规，电流供应和吸收能力。LINEAR的降压µModule®稳压器对于想要高效可靠的电源管理解决方案而又面临时间和空间限制的工程师是有效的。
深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。
详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html
产品型号 | Number of Outputs | Vin (min) | Vin (max) | Output Current (typ) | Output Current 2 (typ) | Vout Min (typ) | Vout Max (typ) |
|
| V | V | A | A | V | V |
LTM4658 | 1 | 2.5 | 5.5 | 10 |
| 500m | 5.5 |
LTM4705 | 2 | 3.1 | 22 | 5 | 5 | 600m | 5.5 |
LTM4670 | 4 | 2.25 | 5.5 | 10 | 10 | 500m | 5.5 |
LTM4673 | 4 | 4.5 | 15 | 12 | 12 | 600m | 3.3 |
LTM4664A | 2 | 30 | 58 | 30 | 30 | 500m | 1.5 |
LTM4660 | 1 | 30 | 60 | 25 |
| 4.5 | 18 |
LTM8060 | 4 | 3 | 40 | 3 | 3 | 800m | 8 |
LTM8051 | 4 | 3 | 40 | 1.2 | 1.2 | 800m | 8 |
LTM4655 | 2 | 3.1 | 40 | 4 | 4 | -26.5 | 26.5 |
LTM4681 | 4 | 4.5 | 16 | 31.25 | 31.25 | 500m | 3.3 |
LTM4657 | 1 | 3.1 | 20 | 8 |
| 500m | 5.5 |
LTM4664 (dual output) | 2 | 30 | 58 | 25 | 25 | 500m | 1.5 |
LTM4664 (single output) | 1 | 30 | 58 | 50 |
| 500m | 1.5 |
LTM4668 | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 1.8 |
LTM4668A | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 5.5 |
LTM4671 | 4 | 3.1 | 20 | 12 | 12 | 600m | 3.3 |
LTM4691 | 2 | 2.25 | 3.6 | 2 | 2 | 500m | 2.5 |
LTM8024 (dual output) | 2 | 3 | 40 | 3.5 | 3.5 | 800m | 8 |
LTM8024 (single output) | 1 | 3 | 40 | 7 |
| 800m | 8 |
LTM4663 |
|
|
|
|
|
|
|
LTM4680 (dual output) | 2 | 4.5 | 16 | 30 | 30 | 500m | 3.3 |
LTM4680 (single output) | 1 | 4.5 | 16 | 60 |
| 500m | 3.3 |
LTM4700 (dual output) | 2 | 4.5 | 16 | 50 | 50 | 500m | 1.8 |
LTM4700 (single output) | 1 | 4.5 | 16 | 100 |
| 500m | 1.8 |
LTM8002 | 1 | 3.4 | 40 | 2.5 |
| 970m | 18 |
LTM8071 | 1 | 3.6 | 60 | 5 |
| 970m | 15 |
LTM8074 | 1 | 3.2 | 40 | 1.2 |
| 800m | 12 |
LTM8078 (dual output) | 2 | 3 | 40 | 1.4 | 1.4 | 800m | 10 |
LTM8078 (single output) | 1 | 3 | 40 | 2.8 |
| 800m | 10 |
LTM4626 | 1 | 3.1 | 20 | 12 |
| 600m | 5.5 |
LTM4638 | 1 | 3.1 | 20 | 15 |
| 600m | 5.5 |
LTM4646 (dual output) | 2 | 4.5 | 20 | 10 | 10 | 600m | 5.5 |
LTM4646 (single output) | 1 | 4.5 | 20 | 20 |
| 600m | 5.5 |
LTM4653 | 1 | 3.1 | 58 | 4 |
| 500m | 54.52 |
LTM4662 (dual output) | 2 | 4.5 | 20 | 15 | 15 | 600m | 5.5 |
LTM4662 (single output) | 1 | 4.5 | 20 | 30 |
| 600m | 5.5 |
LTM4678 (dual output) | 2 | 4.5 | 16 | 25 | 25 | 500m | 3.3 |
LTM4678 (single output) | 1 | 4.5 | 16 | 50 |
| 500m | 3.3 |
LTM4686 (dual output) | 2 | 4.5 | 17 | 10 | 10 | 500m | 3.6 |
