Custom MMIC数字步进衰减器
发布时间：2021-01-18 16:59:27 浏览：1683
Custom MMIC提供多种多样可变衰减器产品，具备高至50GHz的数字或模拟控制能力。Custom MMIC还有一系列以磁芯类型销售的宽带固定衰减器，其频率可以达到50GHz。这类衰减器在绝缘子上应用领域硅(SOI)或PHEMT技术，在频率领域、线性度、开关速率和鲁棒性领域提供广泛性的性能选择。
主要特征
瞬态开关SOIDSA无超调
温度补偿，线性控制斜率SOIVCA
微波射频PHEMT衰减器工作在50GHz
50ns快速开关衰减器
SOI：2ESD性能
典型应用领域
无线基础设施
国防与航天
有线电视
微波射频收音机
测试和测量
深圳市立维创展科技是Custom MMIC的经销商，立维创展协助选取满足需求的最合适的MMIC优化微波射频射频信号链。Custom MMIC是一个完整性的ISO认证和同类型绝佳MMICs经销商。供应迅速增长的高性能射频/微波射频MMIC产品系列。
详情了解Custom MMIC分布式放大器请点击：http://www.leadwaytk.com/brand/2.html
或联络我们的销售工程师：0755-83642657 QQ: 2295048674
Part # | Frequency Min
MHz | Frequency Max
MHz | Insertion Loss
dB | Attenuation Range
dB | IP0.1dB
dBm | IIP3
dBm | Bits | Step Size
dB | Voltage
V | Package Type | Package
mm |
CMD279 | 2,000 | 30,000 | 3.5 | 15.5 | 27 | 42 | 5 | 0.5 | 5 | Die |
|
CMD279C3 | 2,000 | 18,000 | 3.5 | 15.5 | 27 | 42 | 5 | 0.5 | 5 | Ceramic QFN | 3.0 x 3.0 |
CMD280 | DC | 30,000 | 3 | 15.5 | 24 | 42 | 5 | 0.5 | -5 | Die |
|
CMD280C3 | DC | 18,000 | 3 | 15.5 | 24 | 42 | 5 | 0.5 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD281 | DC | 40,000 | 1.2 | 6 | 28 | 42 | 2 | 2 | -5 | Die |
|
CMD281C3 | DC | 22,000 | 1.5 | 6 | 28 | 42 | 2 | 2 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD282 | DC | 40,000 | 1.5 | 12 | 23 | 42 | 2 | 4 | -5 | Die |
|
CMD282C3 | DC | 22,000 | 1.9 | 12 | 23 | 42 | 2 | 4 | -5 | Ceramic QFN | 3.0 x 3.0 |
CMD324 | DC | 30,000 | 2.9 | 30 | 24 | 36 | 2 | 10 | -5 | Die |
|
CMD325 | DC | 30,000 | 4 | 31.5 | 26 | 40 | 6 | 0.5 | -5 | Die |
|
QPC3223 | 50 | 6,000 | 0.8 | 18 | 30 | > 55 | 2 | 6 | 3 to 5 | QFN | 3.0 x 3.0 |
QPC3614 | 5 | 1,500 | 1.2 | 31.5 | 30 | 65 | 6 | 0.5 | 5 | QFN | 4.2 x 4.2 |
QPC3624 | 47 | 2,000 | 1.3 | 31.5 | 30 | 60 | 6 | 0.5 | 5 | QFN | 4.0 x 4.0 x 0.85 |
QPC6614 | 5 | 6,000 | 1.4 | 31.5 | 30 | 55 | 6 | 0.5 | 5 | MCM, 24-Pin | 4.2 x 4.2 x 0.975 |
QPC6713 | 50 | 6,000 | 1.7 | 31.75 | 30 | 55 | 7 | 0.25 | 3 to 5 | QFN | 3.0 x 3.0 x 0.85 |
QPC6713Q | 50 | 6,000 | 1.7 @ 2000 MHz, 3.3 @ 5890 MHz | 31.75 | 30 | > 55 | 7 | 0.25 | 3 to 5 | QFN, 16 pad | 3.0 x 3.0 x 0.85 |
RFSA2534 | 50 | 4,000 | 1.3 | 15.5 | 30 | 52 | 5 | 0.5 | 2.7 to 5.5 | QFN, 24-pin | 4.2 x 4.2 x 0.95 |
RFSA3413 | 5 | 6,000 | 1.4 | 15 | 30 | 55 | 4 | 1 | 5 | QFN | 3.0 x 3.0 |
RFSA3513 | 5 | 6,000 | 1.4 | 31 | 30 | 55 | 5 | 1 | 5 | QFN | 3.0 x 3.0 |
RFSA3613 | 5 | 6,000 | 1.4 | 31.5 | 30 | 55 | 6 | 0.5 | 5 | QFN | 3.0 x 3.0 |
RFSA3713 | 5 | 6,000 | 1.4 | 31.75 | 30 | 55 | 7 | 0.25 | 5 | QFN | 3.0 x 3.0 |
RFSA3714 | 50 | 6,000 | 1.5 | 31.75 | 30 | 55 | 7 | 0.25 | 5 | QFN | 4.0 x 4.0 |
RFSA3715 | 5 | 4,000 | 1.5 | 31.75 | 30 | 50 | 7 | 0.25 | 5 | QFN | 5.0 x 5.0 |
TGL2223-SM | 1,000 | 31,000 | < 4.2 | 15.5 |
| > 32 | 5 | 0.5 | -3.3 to -5.0 | QFN | 3.0 x 3.0 x 1.45 |
TGL2226 | 100 | 15,000 | < 3.8 | 31.5 |
| > 31.5 | 6 | 0.5 | -3.0 to -5.0 | Die | 1.18 x 1.0 x 0.1 |
TGL2226-SM | 100 | 15,000 | < 4.0 | 31.5 |
| > 31.5 | 6 | 0.5 | -3.0 to -5.0 | SMT | 3.0 x 3.0 x 1.5 |
TQP4M9071 | 0 | 4,000 | 1.6 | 31.5 | 30 | 57 | 6 | 0.5 | 5 | QFN, 24-pin | 4.0 x 4.0 x 0.85 |
TQP4M9072 | 0 | 4,000 | 1.6 | 31.5 | 30 | 57 | 6 | 0.5 | 5 | QFN, 24-pin | 4.0 x 4.0 x 0.85 |
