ADI时钟产生器件
发布时间：2023-06-07 16:56:44 浏览：1458
ADI提供极低震动时钟产生器件，适用于无线网络基础设施建设、仪表设备、宽带网络、自动测试设备和具体要求亚皮秒特性的技术应用。ADI时钟产生器件特别适合为性能卓越模数转换器(ADC)和数模转换器(DAC)提供高速度、低噪音时钟信号。ADI的时钟IC在中小型芯片级封装中集成化PLL核心、分频器、相位调制、偏移调整和时钟驱动器。
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。大部分产品，均提供现货库存供货。
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
产品型号 | Output Frequency (max) | Power (typ) | Ref Clock (min) | Ref Clock (max) |
| Hz | W | Hz | Hz |
ADF4377 | 12.8G |
| 10M | 1G |
AD9546 | 500M | 630m | 1 | 750M |
LTC6952 | 4.5G | 2.6 | 1M | 500M |
AD9542 | 500M | 560m | 2k | 750M |
AD9543 | 500M | 560m | 2k | 750M |
AD9544 | 500M | 560m | 1 | 750M |
AD9545 | 500M | 560m | 1 | 750M |
AD9576 | 1.25G | 619m | 8k | 325M |
AD9530 | 2.7G | 2.3 | 6M | 800M |
LTC6951 | 2.5G | 1.1 | 1M | 425M |
LTC6951-1 | 2.7G | 1.1 | 1M | 425M |
AD9531 | 400M | 600m | 9.5M | 260M |
HMC7044 | 3.2G | 3.4 | 150 | 3.2G |
AD9528 | 1.25G | 1.675 |
| 400M |
AD9574 | 312.5M | 569m | 19.44M | 25M |
AD9578 | 919M | 618m | 20M | 60M |
MAX31180 | 134M |
|
|
|
AD9525 | 3.6G | 1.2 | 0M | 500M |
AD9577 | 637.5M | 1 | 19.44M | 54M |
AD9523-1 | 1G | 898m |
| 400M |
AD9550 | 810M | 450m | 8k | 200M |
AD9523 | 1G | 876m | 42M | 400M |
AD9524 | 1G | 559m | 42M | 400M |
AD9553 | 810M | 450m | 8k | 710M |
AD9575 | 312.5M | 350m | 19.44M | 25.7812M |
AD9571 | 156.25M | 690m | 25M | 25M |
AD9552 | 900M | 400m | 6.6M | 112.5M |
AD9572 | 156.25M | 1 | 25M | 25M |
AD9573 | 100M | 235m | 10M | 25M |
AD9551 | 900M | 560m | 10M | 806M |
AD9516-5 | 2.4G | 1.5 | 0M | 250M |
AD9522-1 | 800M | 1.1 | 0M | 250M |
AD9522-2 | 800M | 1.1 | 0M | 250M |
AD9522-5 | 800M | 1.1 | 0M | 250M |
AD9520-0 | 2.4G | 1.5 | 0M | 250M |
AD9520-1 | 2.4G | 1.5 | 0M | 250M |
AD9520-2 | 2.4G | 1.5 | 0M | 250M |
AD9520-3 | 2.4G | 1.5 | 0M | 250M |
AD9520-4 | 2.4G | 1.5 | 0M | 250M |
AD9520-5 | 2.4G | 1.4 | 0M | 250M |
AD9522-0 | 800M | 1.1 | 0M | 250M |
AD9522-3 | 800M | 1.1 | 0M | 250M |
AD9522-4 | 800M | 1.1 | 0M | 250M |
AD9518-0 | 2.95G | 1.1 | 0M | 250M |
AD9518-1 | 2.95G | 1.1 | 0M | 250M |
AD9518-2 | 2.95G | 1.1 | 0M | 250M |
AD9518-3 | 2.95G | 1.1 | 0M | 250M |
AD9518-4 | 2.95G | 1.1 | 0M | 250M |
AD9516-2 | 2.95G | 1.6 | 0M | 250M |
AD9516-3 | 2.95G | 1.6 | 0M | 250M |
AD9517-0 | 2.95G | 1.4 | 0M | 250M |
AD9517-1 | 2.95G | 1.4 | 0M | 250M |
AD9517-2 | 2.95G | 1.4 | 0M | 250M |
AD9517-3 | 2.95G | 1.4 | 0M | 250M |
AD9517-4 | 2.95G | 1.4 | 0M | 250M |
AD9516-0 | 2.95G | 1.6 | 0M | 250M |
AD9516-1 | 2.95G | 1.6 | 0M | 250M |
AD9516-4 | 2.95G | 1.6 | 0M | 250M |
DS1080L | 134M |
|
|
|
AD9510 | 1.2G | 550m | 0M | 250M |
AD9511 | 1.2G | 550m | 0M | 250M |
AD9512 | 1.2G | 800m | 0M | 1.6G |
AD9540 | 655M | 400m | 10M | 655M |
