ADI模拟控制可变增益放大器(VGA)
发布时间：2022-12-28 16:43:37 浏览：633
ADI模拟控制可变增益放大器(VGA)各种各样音频视频和光频频段能够在宽动态范围之内提供连续性增益控制。ADI模拟控制可变增益放大器允许用户实时调整信号幅度，从而优化了电源的动态范围，对于超声波、语音分析、雷达天线、无线通讯和仪表设备相关技术极为重要，所有的应用一般使用模拟控制VGA。
除模拟控制可变增益值放大器外，ADI离散级增益控制还提供了数字控制可变增益值放大器产品线。根据提供模拟控制VGA和数字控制VGA，ADI为管控动态范围提供解决方案，能够轻松管理数字控制和增益值之间的平稳运行。
ADI公司为锂离子电池、铅酸电池、镍基电池等所有可充电电池化学应用制造出深厚的性能卓越脉冲电池充电器。LINEAR脉冲充电器无需微控制器/MOSFET/堵塞二极管，提供开关充电器等诸多优势，简单性和线性充电器相似。
深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。
详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html
产品型号 | Freq Response (min) | Freq Response (max) | Gain dB (min) | Gain dB (max) | OIP3 (typ) | NF (typ) | Is (typ) | Vs span (min) | Vs span (max) |
| Hz | Hz | dB | dB | dBm | dB | A | V | V |
ADRF6521 | 10M | 3G | -3 | 18 |
| 10.5 | 200m | 4.75 | 5.25 |
ADL5246 | 600M | 3G | -13.5 | 31.5 | 37 | 1.8 | 270m | 3.135 | 5.25 |
AD8338 | 0 | 18M | 0 | 80 |
|
| 3m | 3 | 5 |
AD8367S | 10M | 500M | -2.5 | 42.5 |
|
| 39m | 3 | 5.25 |
MAX19791 | 50M | 4G |
| -3.9 |
|
| 13m | 3.15 | 5.25 |
MAX19793 | 1.5G | 6G |
| -7.6 |
|
| 13m | 3.15 | 5.25 |
MAX19794 | 10M | 500M |
| -3 |
|
| 13m | 3.15 | 5.25 |
MAX2092 | 700M | 2.7G |
| 18.1 | 32.5 | 5.2 | 93m | 4.75 | 5.8 |
HMC6187 | 27G | 31.5G | 6 | 19 | 31 | 4.5 | 230m | -5 | 4 |
MAX2090 | 50M | 1G |
| 25.5 | 38 | 4 | 85m | 4.75 | 5.8 |
MAX2091 | 50M | 500M |
| 23 | 24.5 | 5.4 | 254m | 4.75 | 5.8 |
HMC996 | 5G | 12G | -3.5 | 18.5 | 34 | 2 | 120m | 5 | 5.5 |
HMC997 | 17G | 27G | 5.5 | 20.5 | 30 | 3.5 | 170m | 5 | 5 |
MAX19790 | 250M | 4G |
| -4.4 | 31.9 | 4.4 | 7.3m | 4.75 | 5.25 |
AD8264 | 0 | 235M | 0 | 24 |
|
| 99m | 5 | 10 |
ADL5331 | 1M | 1.2G | -14 | 17 | 47 | 9 | 240m | 4.75 | 5.25 |
LTC6412 |
| 800M | -14 | 17 | 35 | 10 | 110m | 3 | 3.6 |
MAX2067 | 50M | 1G |
| 21.9 | 43 | 4 | 123m | 3.135 | 5.25 |
HMC694-Die | 6G | 17G | 1 | 24 | 30 | 5 | 170m | 5 | 5.5 |
HMC694LP4 | 6G | 17G | 0 | 23 | 30 | 6 | 175m | 5 | 5.5 |
MAX2065 | 50M | 1G |
| 19.4 | 42 | 6.5 | 124m | 3.135 | 5.25 |
AD8336 | 0 | 115M | -14 | 46 |
|
| 25m | 6 | 24 |
AD8334 | 100k | 100M | 4.5 | 43.5 |
|
| 116m | 4.5 | 5.5 |
AD8368 | 10M | 800M | -12 | 22 | 34 | 9.5 | 60m | 4.75 | 5.5 |
AD8337 | 0 | 100M | 0 | 24 |
|
| 15m | 4.5 | 10 |
ADL5330 | 10M | 3G | -32 | 21 | 31.5 | 9 | 215m | 4.75 | 5.25 |
MAX2056 | 800M | 1G |
| 15.5 | 39 | 4.5 | 136m | 4.75 | 5.25 |
MAX2057 | 1.3G | 2.7G |
| 15.5 | 37 | 6 | 180m | 4.75 | 5.25 |
AD8335 | 100k | 70M | -10 | 38 |
|
| 76m | 4.5 | 5.5 |
AD8331 | 100k | 120M | -4.5 | 43 |
| 4.15 | 25m | 4.5 | 5.5 |
AD8351 | 1M | 2.2G | 0 | 26 | 31 | 15.5 | 28m | 3 | 5.5 |
AD8330 | 0 | 150M | 0 | 50 |
|
| 20m | 2.7 | 6 |
AD8332 | 100k | 100M | -4.5 | 43.5 |
| 4.2 | 58m | 4.5 | 5.5 |
AD8367 | 10M | 500M | -2.5 | 42.5 | 36.5 | 6.2 | 26m | 2.7 | 5.5 |
AD604 | 100k | 40M | 0 | 48 |
| 8.4 | 31m | 10 | 10 |
AD605 | 100k | 40M | -14 | 34 |
| 8.4 | 23m | 4.5 | 5.5 |
AD603 | 16k | 90M | -11 | 31 |
| 8.8 | 20m |
| 6.3 |
AD600 | 100k | 10M | 0 | 40 |
|
| 14m | 4.75 | 5.25 |
AD602 | 100k | 10M | -10 | 30 |
|
| 14m |
| 5.25 |
