ADI单输出压控振荡器(VCO)
发布时间：2022-12-02 17:04:15 浏览：565
ADI压控振荡器(VCO)锁相振荡器(PLO)产品线适用多种应用。ADI多样化的产品线包含多种机器设备，选用单芯片构造，在环境温度、冲击和工艺参数下具备优异的相位噪声性能指标。ADI为满足多元化设计的需求，还提供了超小型、低相位噪声、低功耗、宽调谐范围选择。
应用：
•点到点及点到多点无线通信
•检测设备和工业控制系统
•SATCOM
•医疗器械
•军用雷达、EW和ECM
•VSAT
•无线网络基础设施
ADI公司为锂离子电池、铅酸电池、镍基电池等所有可充电电池化学应用制造出深厚的性能卓越脉冲电池充电器。LINEAR脉冲充电器无需微控制器/MOSFET/堵塞二极管，提供开关充电器等诸多优势，简单性和线性充电器相似。
深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。
详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html
产品型号 | Freq Response RF (max) | Freq Response RF (min) | Phase Noise @ 10k | Phase Noise @ 100k | Output Power (typ) | Vtune (min) | Vtune (max) | Vs (typ) | Is (typ) |
| Hz | Hz | dBc/Hz | dBc/Hz |
| V | V | V | A |
HMC6380 | 16G | 8G | -64 | -92 | 6 dBm | 0 | 23 | 5 | 75m |
HMC732 | 12G | 6G | -65 | -95 | 1 dBm | 0 | 23 | 5 | 57m |
HMC733 | 20G | 10G | -60 | -90 | 2 dBm | -0.25 | 23 | 5 | 70m |
HMC532 | 7.9G | 7.1G | -80 | -101 | 14 dBm | 1 | 13 | 3 | 85m |
HMC586 | 8G | 4G | -75 | -100 | 5 dBm | 0 | 18 | 5 | 55m |
HMC587 | 10G | 5G | -65 | -95 | 5 dBm | 0 | 18 | 5 | 55m |
HMC505 | 7.4G | 6.8G | -80 | -106 | 11 dBm | 1 | 11 | 3 | 80m |
HMC506 | 8.7G | 7.8G | -80 | -103 | 14 dBm | 1 | 11 | 3 | 77m |
HMC385 | 2.5G | 2.25G | -89 | -115 | 4.5 dBm | 0 | 10 | 3 | 35m |
HMC386 | 2.8G | 2.6G | -88 | -115 | 5 dBm | 0 | 10 | 3 | 35m |
HMC388 | 3.4G | 3.15G | -88 | -113 | 4.9 dBm | 0 | 10 | 3 | 39m |
HMC389 | 3.55G | 3.35G | -89 | -112 | 4.7 dBm | 0 | 10 | 3 | 41m |
HMC390 | 3.9G | 3.55G | -87 | -112 | 4.7 dBm | 0 | 10 | 3 | 42m |
HMC391 | 4.45G | 3.9G | -81 | -106 | 5 dBm | 0 | 10 | 3 | 30m |
HMC416 | 3G | 2.75G | -89 | -114 | 4.5 dBm | 0 | 10 | 3 | 37m |
HMC429 | 5G | 4.45G | -79 | -105 | 4 dBm | 0 | 10 | 3 | 30m |
HMC466 | 6.72G | 6.1G | -73 | -101 | 4.5 dBm | 0 | 10 | 3 | 13m |
HMC358 | 6.8G | 5.8G | -82 | -110 | 11 dBm | 0 | 10 | 3 | 100m |
HMC384 | 2.25G | 2.05G | -89 | -112 | 3.5 dBm | 0 | 10 | 3 | 35m |
HMC430 | 5.5G | 5G | -80 | -103 | 2 dBm | 0 | 10 | 3 | 27m |
HMC431 | 6.1G | 5.5G | -80 | -102 | 2 dBm | 0 | 10 | 3 | 27m |
HMC6475 | 7.5G | 3.9G | -79 | -106 | 5 dBm | 0 | 23 | 0 | 53m |
