Custom MMIC低噪声放大器有哪些特点与应用？
发布时间：2020-08-11 16:22:57 浏览：1481
2020年2月，Qorvo宣布收购用于国防、航天和商业用途的GaN单芯片微波集成电路的领先供应商Custom MMIC、高性能砷化镓和(MMIC)。作为Qorvo基础设施和国防产品业务的一部分，Custom MMIC将继续扩大其用于防御相控阵和AESA雷达、电子战、卫星通信、无线回程和微波测试产品设备的毫米波能力。
Custom MMIC成立于2006年，在开发高达70 GHz频率的MMIC方面具有丰富的经验。Custom MMIC增加了小信号mmWave的专业知识，并提供180多个标准产品组合，包括LNA、混合器、衰减器、移相器和开关。
Qorvo提供各种工业领先的低噪音性能晶体管和放大器。包括分立晶体管、集成内部匹配和片内线性化的封装mmMIC解决方案，以及配置为推挽或平衡放大器的双放大器。
Custom MMIC低噪声放大器的主要特性
超低噪音系数-低至0.4dBNF
与大多数设备集成的有源偏置
大部分零件的片上匹配集成
可提供模具或包装
Custom MMIC低噪声放大器的应用
汽车工业
基站
有线电视(CATV)/光纤到家庭(FTTH)
国防通讯
光学
点对点(Ptp)无线电
深圳市立维创展科技是Custom MMIC的经销商，立维创展协助选取满足需求的最合适的MMIC优化微波射频射频信号链。Custom MMIC是一个完整性的ISO认证和同类型绝佳MMICs经销商。供应迅速增长的高性能rf射频/微波射频rf射频MMIC产品系列。
详情了解Custom MMIC功率放大器请点击：http://www.leadwaytk.com/brand/2.html
或联络我们的销售工程师：0755-83642657 QQ: 1369964087
Part # | Frequency Min
GHz | Frequency Max
GHz | Gain
dB | NF
dB | OP1dB
dBm | OIP3
dBm | Voltage
V | Current
mA |
CMD119P3 | 5 | 9 | 22 | 1.2 | 11 | 21 | 2 to 4.5 | 30 |
CMD132 | 5 | 11 | 23 | 1.4 | 10 | 22 | 2 to 4.5 | 30 |
CMD132P3 | 5 | 11 | 21 | 1.4 | 10 | 22 | 2 to 4.5 | 30 |
CMD157 | 6 | 18 | 26 | 1.5 | 11 | 23 | 2 to 4.5 | 52 |
CMD157P3 | 6 | 18 | 26 | 1.5 | 11 | 23 | 2 to 4.5 | 52 |
CMD160C4 | 17 | 25 | 26.5 | 1.6 | 8 | 16 | 2 to 4 | 26 |
CMD162 | 26 | 34 | 22 | 1.7 | 7 | 14 | 1 to 4 | 25 |
CMD163 | 17 | 27 | 24 | 1.3 | 19 | 26 | 2 to 4 | 120 |
CMD163C4 | 17 | 27 | 23 | 1.7 | 18 | 26 | 2 to 4 | 120 |
CMD167 | 10 | 17 | 15 | 2 | 11 | 24 | 2 to 4 | 55 |
CMD167P3 | 8 | 16 | 16 | 1.8 | 11 | 23 | 2 to 4 | 50 |
CMD185P3 | 4 | 8 | 15.5 | 1.9 | 15 | 29 | 2 to 5 | 75 |
CMD186P3 | 6 | 11 | 18.5 | 2.1 | 17 | 28 | 2 to 5 | 78 |
CMD188 | 26 | 34 | 20 | 1.4 | 6 | 15 | 1 to 4 | 20 |
CMD189P3 | 10 | 14 | 19 | 1.4 | 4 | 13 | 1 to 4 | 20 |
CMD190 | 33 | 45 | 19 | 2.1 | 4 | 13 | 1 to 4 | 25 |
CMD194C3 | 6 | 20 | 20 | 2 | 15.5 | 26 | 2 to 5 | 120 |
CMD218 | 5 | 9 | 22 | 1.1 | 21.5 | 30 | 5 to 28 | 80 |
CMD218C4 | 5 | 9 | 22 | 1.1 | 18.5 | 29 | 5 to 28 | 75 |
CMD219 | 4 | 8 | 23 | 1 | 18 | 28 | 5 to 28 | 75 |
CMD219C4 | 4 | 8 | 22.5 | 1 | 17 | 28 | 5 to 28 | 75 |
CMD228 | 2 | 6 | 30 | 1.2 | 12 | 23 | 3 to 5 | 45 |
CMD228P4 | 2 | 6 | 28 | 1.5 | 13 | 25 | 3 to 5 | 45 |
CMD229P4 | 5 | 11 | 26 | 1.5 | 13 | 24 | 3 to 5 | 45 |
CMD263 | 5 | 11 | 23 | 1.4 | 11 | 23 | 2 to 4.5 | 35 |
CMD263P3 | 5 | 11 | 22 | 1.4 | 11 | 21 | 2 to 4.5 | 35 |
CMD264 | 6 | 18 | 26 | 1.5 | 13 | 27 | 2 to 4.5 | 63 |
CMD264P3 | 6 | 18 | 26 | 1.7 | 13 | 24 | 2 to 4.5 | 63 |
CMD270 | 4 | 8 | 15.5 | 1.8 | 16 | 30 | 2 to 5 | 60 |
CMD270P3 | 4 | 8 | 16 | 1.7 | 18 | 31 | 2 to 5 | 60 |
CMD271 | 6 | 11 | 20 | 2.0 | 16.5 | 27 | 5 | 66 |
CMD271P3 | 6 | 11 | 20 | 1.8 | 16.5 | 27 | 3 to 5 | 66 |
CMD276C4 | 2.6 | 4 | 14.5 | 1.2 | 25.5 | 32 | 5 to 28 | 225 |
CMD277C4 | 5 | 7 | 20 | 1.2 | 26.5 | 33.5 | 5 to 28 | 200 |
CMD278 | 8 | 12 | 15 | 1.8 | 28 | 33 | 5 to 28 | 280 |
CMD278C4 | 8 | 12 | 15 | 1.8 | 28 | 33 | 5 to 28 | 280 |
CMD283 | 2 | 6 | 27 | 0.6 | 16 | 26 | 2 to 5 | 42 |
CMD283C3 | 2 | 6 | 27 | 0.6 | 16 | 26 | 2 to 5 | 42 |
CMD290 | 2 | 26 | 12.5 | 2.3 | 19 | 27 | 10 to 28 | 100 |
CMD298 | 17 | 25 | 27 | 1.4 | 8 | 17 | 3 | 27 |
CMD298C4 | 17 | 25 | 27 | 1.4 | 8 | 19 | 1.5 to 3.5 | 27 |
CMD299 | 18 | 40 | 17 | 3.5 | 8 | 17 | 3 | 33 |
CMD299K4 | 18 | 40 | 16 | 4 | 7 | 18 | 3 | 33 |
CMD307 | 8 | 16 | 19.5 | 1.8 | 12 | 25 | 2 to 4 | 51 |
CMD307P3 | 8 | 16 | 17 | 2 | 12 | 25 | 2 to 4 | 55 |
CMD308 | 2 | 6 | 32 | 1.5 | 12 | 23 | 3 to 5 | 45 |
CMD308P4 | 2 | 6 | 31 | 1.6 | 12 | 22.5 | 3 to 5 | 45 |
CMD309 | 5 | 12 | 29.5 | 1.3 | 13 | 24 | 3 to 5 | 45 |
CMD309P4 | 5 | 11 | 27 | 1.5 | 13 | 23 | 3 to 5 | 45 |
CMD316 | 6 | 20 | 20.5 | 2 | 15 | 25 | 3 to 5 | 100 |
CMD316C3 | 6 | 20 | 21 | 2 | 15 | 25 | 3 to 5 | 100 |
CMD318P3 | 5 | 9 | 22 | 1.25 | 14 | 25.5 | 2.5 to 4.5 | 33 |
CMD319C3 | 8 | 12 | 20 | 0.92 | 16 | 22 | 3 | 30 |
CMD320C3 | 10.7 | 12.7 | 18 | 1.07 | 16 | 23 | 3 | 32 |
QPA2609 | 7 | 14 | 26 | 1.1 | 18 |
| 3.5 | 120 |
QPA2609D | 7 | 14 | 27 | 1.1 | 18 |
| 3.5 | 120 |
QPA2626 | 17 | 22 | 25 | 1.3 | 20 | 28 | 3.5 | 90 |
QPA2626D | 17 | 23 | 25 | 1.3 | 20 |
| 3.5 | 90 |
QPA2628 | 22 | 32 | 23 | 1.6 | 19 | 27 | 3.5 | 90 |
QPA2628D | 25 | 31 | 22 | 1.7 | 19 | 27 | 3.5 | 90 |
QPA2735 | 13 | 20 | 26 | 1.1 | 18 |
| 3.5 | 105 |
QPA2735D | 13 | 20 | 26 | 1.2 | 18 |
| 3.5 | 105 |
QPL1002 | 0.03 | 3 | 17 | 1.2 | 23 |
| 12 | 50 |
QPL2210 | 10 | 13 | 16 | 1.2 |
|
| 2 | 11 |
QPL2210D | 10.5 | 12.7 | 17 | 1.1 | 1 |
| 2 | 11 |
QPL6202Q | 2.32 | 2.345 | 21.8 | 0.52 | 19.9 | 39.9 | 4.5 | 55 |
QPL6207Q | 2.32 | 2.345 | 18.5 | 0.45 | 21.5 | 35 | 4.5 | 55 |
QPL6208Q | 2.32 | 2.345 | 13 | 0.48 | 19.6 | 37 | 3.6 | 53 |
QPL6216Q | 2.32 | 2.345 | 15.1 | 0.45 | 22.5 | 36 | 4.5 | 60 |
QPL7442 | 0.05 | 4 | 20 | 1.5 | 20 | 30 | 5 | 85 |
QPL9057 | 0.6 | 4.2 | 22.8 | 0.54 | 17 | 32 | 5 | 50 |
QPL9065 | 0.45 | 3.8 | 37.5 | 0.55 | 20.8 | 35 | 5 | 160 |
QPL9095 | 0.6 | 1 | 22 | 0.6 | 20 | 34 | 4.2 | 55 |
QPL9096 | 1.7 | 2.7 | 22 | 0.7 | 20 | 34 | 4.2 | 60 |
QPL9097 | 3.3 | 4.2 | 22 | 1.1 | 15.5 | 34 | 4.2 | 50 |
QPL9503 | 0.6 | 6 | 21.6 | 0.9 | 19 | 35 | 5 | 65 |
QPL9547 | 0.1 | 6 | 19.3 | 0.3 | 22.7 | 39.3 | 5 | 65 |
QPM1000 | 2 | 20 | > 17 | 1.7 to 4.0 | > 17 |
| 5 | 100 |
QPM6000 | 8 | 14 | 23 | 1.6 |
|
| 2 | 180 |
RF2373 | 0.4 | 3.8 | 15 | 1.3 | 11.5 | 24.5 | 3.3 | 14 |
RF2815 | 1.5 | 1.6 | 13.5 | 0.85 | 10.5 | 21.5 | 2.85 | 8 |
RF2818 | 1.5 | 1.6 | 14 | 1.55 | 8 | 20 | 2.7 | 7 |
RF2878 | 0.15 | 2.5 | 13 | 1.3 |
| 29.5 | 3 | 7 |
RFLA9002 | 0.698 | 0.96 | 17.5 | 1 | 17.5 | 22.5 | 4 | 12 |
RFLA9003 | 1.71 | 2.18 | 18 | 1.2 | 14.5 | 27 | 4 | 29 |
SGA8343Z | 0.05 | 4 | 16.5 | 1.4 | 9 | 27.8 | 3.3 | 10 |
SGL0622Z | 0.005 | 4 | 24 | 2 | 1 | 9 | 3.3 | 10.5 |
SPF5043Z | 0.05 | 4 | 12.9 | 0.8 | 22.7 | 35 | 5 | 46 |
SPF5122Z | 0.05 | 4 | 12.2 | 0.65 | 23.4 | 40.5 | 5 | 90 |
SPF5189Z | 0.05 | 4 | 12.8 | 0.8 | 22.7 | 39.5 | 5 | 90 |
SPF5344Z | 0.8 | 4 | 24.5 | 0.8 | 22.4 | 39 | 5 | 120 |
TGA2227 | 2 | 22 | 16 | 2.5 | 20.3 |
| 8 | 125 |
TGA2227-SM | 2 | 22 | 15.7 | 2.6 | > 23 |
| 8 | 125 |
TGA2512 | 4 | 14 | 27 | 1.4 | 13 | 24 | 5 | 160 |
TGA2512-1-SM | 4 | 14 | 22 | 2.3 | 6 | 16 | 5 | 160 |
TGA2512-2-SM | 4 | 14 | 25 | 2.3 | 13 | 24 | 5 | 160 |
TGA2525 | 2 | 18 | 17 | 2 | 17 | 29 | 5 | 75 |
TGA2526 | 2 | 20 | 17.5 | 2.5 | 20 | 30 | 5 | 100 |
TGA2567-SM | 2 | 20 | 17 | 2 | 19 | 29 | 5 | 100 |
TGA2611 | 2 | 6 | 25 | 1.5 | 22 | 32 | 10 | 110 |
TGA2611-SM | 2 | 6 | 22 | 1 | 18 | 30 | 10 | 100 |
TGA2613 | 2.5 | 4 | 12.5 | 2.5 | 29 | 29 | 6 | 320 |
TGA2618 | 16 | 18 | 28 | 2.3 | 6 | 13 | 3 | 30 |
TGA4506 | 20 | 27 | 21 | 2.2 | 12 |
| 3.5 | 60 |
TGA4508 | 30 | 42 | 21 | 2.8 | 14 |
| 3 | 40 |
TQL9066 | 0.05 | 1.5 | 18.4 | 0.62 | 21.4 | 40 | 5 | 55 |
TQL9092 | 0.6 | 4.2 | 22.6 | 0.53 | 19 | 37 | 5 | 67 |
TQL9093 | 0.6 | 4.2 | 20 | 0.67 | 21.7 | 41.5 | 5 | 120 |
TQP3M9005 | 0.05 | 4 | 15.3 | 0.8 | 22.3 | 34 | 5 | 50 |
TQP3M9006 | 0.5 | 4 | 13.5 | 1 | 22.4 | 38.5 | 5 | 90 |
TQP3M9007 | 0.1 | 4 | 13 | 1.3 | 23.6 | 41 | 5 | 125 |
TQP3M9008 | 0.05 | 4 | 20.6 | 1.3 | 20 | 36 | 5 | 85 |
TQP3M9009 | 0.05 | 4 | 21.8 | 1.3 | 22 | 39.5 | 5 | 125 |
TQP3M9018 | 0.02 | 4 | 20.5 | 1.3 | 21 | 37 | 5 | 85 |
TQP3M9019 | 0.02 | 4 | 22 | 1.3 | 22 | 39.5 | 5 | 125 |
TQP3M9035 | 0.05 | 6 | 16.5 | 0.65 | 22.5 | 37 | 5 | 115 |
TQP3M9036 | 0.05 | 2 | 19.8 | 0.45 | 20 | 36 | 5 | 68 |
TQP3M9037 | 0.7 | 6 | 20 | 0.4 | 20 | 35 | 5 | 70 |
TQP3M9039 | 0.05 | 1.5 | 18 | 0.6 | 21.5 | 38.8 | 5 | 57 |
TQP3M9040 | 1.5 | 2.3 | 18 | 0.62 | 20.8 | 39.8 | 5 | 57 |
TQP3M9041 | 2.3 | 6 | 18.4 | 0.8 | 22.5 | 38.2 | 5 | 57 |
