Model | Power | Input Voltage | Output Voltage | Features | Dimensions (Inch) |
EC3AW | 3W | 18~72V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 500/1.5K/3KVdc Isolation | 1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24) |
EC4AW | 6W | 18~72V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 1.5K/3KVdc Isolation | 1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24) |
EC6AW | 8W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 1.5KVdc Isolation
EN50155 Compliant | 1.25x0.80x0.40(DIP24)
1.25×0.80x0.45(SMD24) |
EC2SBW | 10W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 1.5KVdc Isolation | 1.00x1.00x0.40(DIP) |
EC4BW | 10W | 18~72V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 500Vdc Isolation
EN55022 Class A | 2.00x1.00x0.40(DIP) |
EC7AW | 10W | 18~74V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 3KVdc Isolation
EN55032 Class A | 1.25x0.80x0.40(DIP24) |
EC6AW-110 | 10W | 43~160V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 3KVdc Isolation
UL60950-1 & CB
EN45545-2
EN50155 Compliant | 1.25x0.80x0.50(DIP24) |
EC8AW | 15W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 1.5KVdc Isolation
EN55032 Class A | 1.25x0.80x0.40(DIP24) |
EC3SBW | 15W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 1.5KVdc Isolation | 1.00x1.00x0.40(DIP) |
EC5BW | 15W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | 1.5KVdc Isolation
EN55032 Class A | 2.00x1.00x0.40(DIP) |
EC5C | 15W | 18~72V, 9~36V | 12V, 15V, 3.3V, 5/±12V, 5/±15V, 5V, ±12V, ±15V, ±5V | 500Vdc Isolation
EN60950-1 | 2.00x2.00x0.40(DIP) |
EC1SC | 20W | 18~72V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±5V | EN55022 Class A | 2.00×1.60×0.45(DIP) |
EC4SBW | 20W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 1.5KVdc Isolation | 1.00x1.00x0.40(DIP) |
EC7BW-110 | 20W | 43~160V | 5V, 12V, 15V, ±12V, ±15V | 3KVdc Isolation
UL60950-1
EN45545-2
EN50155 Compliant | 2.00x1.00x0.40(DIP) |
EC7BW | 20W | 9~36V, 18~75V | 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.5KVdc Isolation
EN45545-2
EN50155 Compliant | 2.00x1.00x0.40(DIP) |
EC3SCW | 30W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V | 1.5KVdc Isolation
EN60950-1 | 2.00×1.60×0.40(DIP) |
EC5SBW | 30W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 1.5KVdc Isolation
UL62368-1 | 1.00x1.00x0.40(DIP) |
EC9BW | 30W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 1.5KVdc Isolation | 2.00x1.00x0.40(DIP) |
ECLB40W | 40W | 18~75V, 9~36V | 12V, 15V, 3.3V, 5V, ±12V, ±15V | 1.5KVdc Isolation
With Mounting Inserts | 2.05x1.20x0.40(DIP) |
ECLB40W-110 | 40W | 43~160V | 12V, 15V, 3.3V, 5V, ±12V, ±15V, ±24V | 3KVdc Isolation
UL60950-1
EN45545-2
EN50155 Compliant | 2.05x1.20x0.40(DIP) |
ECLB60W | 60W | 18~75V, 9~36V | 3.3V, 5V, 12V, 15V, ±12V, ±15V | 1.5KVdc Isolation
With Mounting Inserts | 2.05x1.20x0.40(DIP) |
ECLB75W | 75W | 18~75V, 9~36V | 5V, 12V, 15V, ±12V, ±15V, ±24V | 2.25KVdc Isolation
With Mounting Inserts | 2.05x1.20x0.40(DIP) |
