692X-B/39/383

X-Band
Q-Band

8.2-12.4
33-50

WR-90 Waveguide with UG-39/U Flange
WR-22 Waveguide, UG-383/U Flange

1.10:1

692X-Ku/39/419

X-Band
Ku-Band

8.2-12.4
12.4-18

WR-90 Waveguide with UG-39/U Flange
WR-62 Waveguide, UG-419/U Flange

1.10:1

692Ku-K/419/595

Ku-Band
K-Band

12.4-118
18-26.5

WR-62 Waveguide, UG-419/U Flange
WR-42 Waveguide, UG-595/U Flange

1.10:1

692K-B/595/383

K-Band
Q-Band

18-26.5
33-50

WR-42 Waveguide, UG-595/U Flange
WR-22 Waveguide, UG-383/U Flange

1.10:1

692K-A/595/599

K-Band
Ka-Band

18-26.5
26.5-40

WR-42 Waveguide, UG-595/U Flange
WR-28 Waveguide, UG-599/U Flange

1.10:1

692A-H/599/387

Ka-Band
H-Band

26.5-40
170-260

WR-28 Waveguide, UG-599/U Flange
WR-04 Waveguide, UG-387/U-M Flange

1.15:1

692A-U/599/383

Ka-Band
U-Band

26.5-40
40-60

WR-28 Waveguide, UG-599/U Flange
WR-19 Waveguide, UG-383/U-M Flange

1.10:1

692A-V/599/385

Ka-Band
V-Band

26.5-40
50-75

WR-28 Waveguide, UG-599/U Flange
WR-15 Waveguide, UG-385/U Flange

1.10:1

692B-U/383

Q-Band
U-Band

33-50
40-60

WR-22 Waveguide, UG-383/U Flange
WR-19 Waveguide, UG-383/U-M Flange

1.10:1

692B-V/383/385

Q-Band
V-Band

33-50
50-75

WR-22 Waveguide, UG-383/U Flange
WR-15 Waveguide, UG-385/U Flange

1.10:1

692U-V/383/385

U-Band
V-Band

40-60
50-75

WR-19 Waveguide, UG-383/U-M Flange
WR-15 Waveguide, UG-385/U Flange

1.10:1

692V-E/385/387

V-Band
E-Band

50-75
60-90

WR-15 Waveguide, UG-385/U Flange
WR-12 Waveguide, UG-387/U Flange

1.10:1

692E-W/387

E-Band
W-Band

60-90
75-110

WR-12 Waveguide, UG-387/U Flange
WR-10 Waveguide, UG-387/U-M Flange

1.10:1

692W-D/387

W-Band
D-Band

75-110
110-170

WR-10 Waveguide, UG-387/U-M Flange
WR-06 Waveguide, UG-387/U-M Flange

1.15:1

692W-F/387

W-Band
F-Band

75-110
90-140

WR-10 Waveguide, UG-387/U-M Flange
WR-8 Waveguide, UG-387/U-M Flange

1.12:1

692W-J/387

W-Band
J-Band

75-110
220-325

WR-10 Waveguide, UG-387/U-M Flange
WR-03 Waveguide, UG-387/U-M Flange

1.15:1

692F-D/387

F-Band
D-Band

90-140
110-170

WR-08 Waveguide, UG-387/U Flange
WR-06 Waveguide, UG-387/U-M Flange

1.15:1

692D-G/387

D-Band
G-Band

110-170
140-220

WR-06 Waveguide, UG-387/U-M Flange
WR-05 Waveguide, UG-387/U-M Flange

1.15:1

692G-H/387

G-Band
H-Band

140-220
170-260

WR-05 Waveguide, UG-387/U Flange
WR-04 Waveguide, UG-387/U-M Flange

1.25:1

692H-J/387

H-Band
J-Band

170-260
220-325

WR-04 Waveguide, UG-387/U Flange
WR-03 Waveguide, UG-387/U-M Flange

1.25:1

692J-(2.2)/387

J-Band
WR-2.2

220-325
330-500

WR-03 Waveguide, UG-387/U Flange
WR-2.2 Waveguide, UG-387/U-M Flange

1.25:1
