产品详情介绍
测试用110GHz毫米波适配线缆2430-00SF 电缆组件由毫米波连接器配接相应的电缆，使用频率为DC-110GHz，具有频带宽、高频性能好、损耗低、连接可靠等特点。由于毫米波连接器采用空气界面, 螺纹连接, 具有体积小、重量轻, 产品可以实现互连等优点，所以DC-110GHz毫米波系列电缆组件被广泛应用于微波测量及空间位置复杂，且性能要求较高的场合。
线缆产品选型如下：
| 1.85 mm (V) to 1.0 mm (W) Adapters (67 GHz) | |
| 1.85 mm (F) to 1.0 mm (F): | 182410-00SF |
| 1.85 mm (F) to 1.0 mm (M): | 182420-00SF |
| 1.85 mm (M) to 1.0 mm (F): | 182430-00SF |
| 1.85 mm (M) to 1.0 mm (M): | 182440-00SF |
| 1.0 mm (W) to 0.9 SuperMini (67 GHz) | |
| 1.0 mm (F) to 0.9 SuperMini (M): | 245220-00SF |
| 1.0 mm (F) to 0.9 SuperMini (F): | 245310-00SF |
| 1.0 mm (W) to SSBP Coax Contacts (110 GHz) | |
| 1.0 mm (F) to SSBP Coax Contacts (F): 195020-01G | 195020-01G |
| 1.0 mm (F) to SSBP Coax Contacts (M): 195110-01G | 195110-01G |
| 1.0 mm (W) Adapters (110 GHz) | |
| 1.0 mm (F) to 1.0 mm (M): | 2430-00SF |
| 1.0 mm (M) to 1.0 mm (M): | 2431-00SF |
| 1.0 mm (F) to 1.0 mm (F): | 2432-00SF |
