32 位 PSoC™ 5 LP Arm® Cortex®-M3 Cypress

发布时间：2023-05-12 16:42:45 浏览：742

Cypress PSoC™5LP根据ArmCortex-M3CPU及其24位高通滤波器块(DFB)、24个UDB和性能卓越DMA控制器提供解决性能。在单独芯片中集成化AFE、数字逻辑电路、操作界面IC和Arm Cortex- M3 CPU可帮助客户减少BOM成本费用。PSoC™5LP提供芯片级封装(CSP)，使客户可以在智能穿戴设备、健身设备和移动终端等超小型应用上采用PSoC的操作灵活性完成设计。

PSoC™5LP根据兼容宽工作电压范围和数个电源域来优化客户的操作系统电源架构模式。

Cypress的PSoC™ Creator采用单一化系统开发环境来编辑、编译和调节客户的PSoC™5LP系统，从而减少客户的成本费用并加速客户的上线时间。PSoC™Creator具备超出150个通过预验证、生产准备的外接器件：可以设置、拖拽、模拟和数字外接设备模块。

特征

32位Arm Cortex-M3 CPU，32个中止输入

24通道直接内存访问(DMA)控制器，能够在外接设备和内存中进行数据传输

24位定点高通滤波器处理器(DFB)

20数个通用型构建块和高精密模拟外接设备

高达62个CapSense®传感器，具备Smart Sense™增益控制性能

具备可编程运算放大器、12位SARADC和8位DAC的多路复用AFE

适用于定制开发显示器736段LCD控制器

封装：68管脚QFN、99管脚WLCSP、100管脚TQFP

深圳市立维创展科技是一家代理经销商，主要提供微波功率放大器芯片和进口电源模块产品，代理品牌包含AMCOM、PICO、Cyntec、CUSTOM MMIC、RF-LAMBDA、ADI、QORVO、MA-COM、SOUTHWEST西南微波等，立维创展致力为客户提供高品质、高质量、价格公正的微波元器件产品。

详情了解Cypress品牌请点击：http://www.leadwaytk.com/article/2126.html

Cypress (2).png

Product	Infineon Package name	Family	ADC (#, Max. Resolution @ Sample Rate)	Operating Voltage min [V]	Operating Voltage max [V]	Operating Temperature min [°C]	Operating Temperature max [°C]	Peak Reflow Temp [°C]
CY8C5266FNI-LP205T	SG-UFWLB-99	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5267AXI-LP051	PG-TQFP-100	PSoC 52LPxxx		1.71	5.5	-40	85	260
CY8C5267LTI-LP089	PG-VQFN-68	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5268AXI-LP047	PG-TQFP-100	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5268LTI-LP030	PG-VQFN-68	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5287AXI-LP095	PG-TQFP-100	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5288FNI-LP213T	SG-UFWLB-99	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5288LTI-LP090	PG-VQFN-68	PSoC 52LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5467AXI-LP108	PG-TQFP-100	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5467LTI-LP003	PG-VQFN-68	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5468AXI-LP042	PG-TQFP-100	PSoC 54LPxxx						260
CY8C5468AXI-LP106	PG-TQFP-100	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5468LTI-LP026	PG-VQFN-68	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5488AXI-LP120	PG-TQFP-100	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5488FNI-LP212T	SG-UFWLB-99	PSoC 54LPxxx	SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5666AXI-LP001	PG-TQFP-100	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5666AXI-LP004	PG-TQFP-100	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5666LTI-LP005	PG-VQFN-68	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5667AXI-LP006	PG-TQFP-100	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5667AXI-LP040	PG-TQFP-100	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5667AXQ-LP040	PG-TQFP-100	PSoC 56LPxxx		1.71	5.5	-40	105	260
CY8C5667LTI-LP009	PG-VQFN-68	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5667LTI-LP041	PG-VQFN-68	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5668AXI-LP010	PG-TQFP-100	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5668AXI-LP013	PG-TQFP-100	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5668AXI-LP034	PG-TQFP-100	PSoC 56LPxxx		1.71	5.5	-40	85	260
CY8C5668LTI-LP014	PG-VQFN-68	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5688AXI-LP099	PG-TQFP-100	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5688LTI-LP086	PG-VQFN-68	PSoC 56LPxxx	SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5866AXI-LP020	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5866AXI-LP021	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5866LTI-LP022	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5867AXI-LP024	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5867LTI-LP025	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5867LTI-LP028	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (1, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5868AXI-LP032	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5868AXI-LP035	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5868LTI-LP038	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5868LTI-LP039	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5888AXI-LP096	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5888AXQ-LP096	PG-TQFP-100	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	105	260
CY8C5888FNI-LP210T	SG-UFWLB-99	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5888FNI-LP214T	SG-UFWLB-99	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5888LTI-LP097	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	85	260
CY8C5888LTQ-LP097	PG-VQFN-68	PSoC 58LPxxx	DelSig (1, 20-bit @ 180 sps), SAR (2, 12-bit @ 1000 ksps)	1.71	5.5	-40	105	260
