LINEAR降压型稳压器和 LDO
发布时间：2022-09-13 16:41:11 浏览：883
LINEAR降压型稳压器和LDO是完整的电源管理解决方案，先进性便携式应用程序基于处理器的系统。LINEAR降压型稳压器和LDO包括四个同步降压DC/DC转换器，适用于核心、内存、I/O和片上系统(SoC)供电轨道和三个300mALDO控制器，适用于低噪音模拟电源。I2C串口适用于控制稳压器使能、关断定时、输出电压水平、动态电压调整、工作模式和状态报告。
ADI公司的隔离µModule®转换器是完整的系统化封装(SiP)电源管理解决方案，LINEAR电源在紧凑型表贴BGA封装内集成DC/D阿C控制器、功率晶体管、输入和输出电容、补偿组件以及725 VDC隔离变压器。LINEAR电源的1.5 W输出隔离反激式µModule转换器可有效满足面对时间和空间限制难题的工程师需要，为全球客户提供高效、可靠的电源管理解决方案。
深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。
详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html
产品型号 | Number of Outputs | Vin (min) | Vin (max) | Buck Output Current (typ) | LDO Output Current (typ) |
|
| V | V | A | A |
ADP5320 | 9 | 1.8 | 5.5 | 150m | 50m, 50m, 50m, 50m, 50m, 50m |
LT3380 | 7 | 2.7 | 5.5 | 1.5, 1.5, 2.5, 2.5 | 300m, 300m, 300m |
LT3383 | 7 | 2.7 | 5.5 | 1.5, 1.5, 2.5, 2.5 | 300m, 300m, 300m |
ADP5138 | 5 | 3 | 5.5 | 1, 1, 1, 1 | 250m |
ADP5003 | 2 | 4.2 | 15 | 3 | 3 |
LT3668 | 3 | 4.3 | 40 | 400m | 200m, 200m |
LT3667 | 3 | 4.3 | 40 | 400m | 200m, 200m |
ADP5080 | 8 | 4 | 15 | 800m, 1.15, 1.5, 2, 3 | 300m, 400m |
ADP5134 | 4 | 2.5 | 5.5 | 1.2, 1.2 | 300m, 300m |
ADP5050 | 5 | 4.5 | 15 | 1.2, 1.2, 4, 4 | 200m |
ADP5052 | 5 | 4.5 | 15 | 1.2, 1.2, 4, 4 | 200m |
LTM8001 | 6 | 6 | 36 | 5 | 1.1, 1.1, 1.1, 1.1, 1.1 |
ADP5040 | 3 | 2.3 | 5.5 | 1.2 | 300m, 300m |
ADP5041 | 3 | 2.3 | 5.5 | 1.2 | 300m, 300m |
ADP1876 | 3 | 2.75 | 20 | 25, 25 | 150m |
ADP5023 | 3 | 2.3 | 5.5 | 800m, 800m | 300m |
ADP5024 | 3 | 2.3 | 5.5 | 1.2, 1.2 | 300m |
ADP5037 | 4 | 2.3 | 5.5 | 800m, 800m | 300m, 300m |
ADP5033 | 4 | 2.3 | 5.5 | 800m, 800m | 300m, 300m |
ADP5034 | 4 | 2.3 | 5.5 | 1.2, 1.2 | 300m, 300m |
LT3507A | 4 | 4 | 36 | 1.8, 1.8, 2.7 | 1 |
ADP5043 | 2 | 2.3 | 5.5 | 800m | 300m |
LT3645 | 2 | 3.6 | 36 | 500m | 200m |
ADP5042 | 3 | 2.3 | 5.5 | 800m | 300m, 300m |
LTC3104 | 2 | 2.5 | 15 | 300m | 10m |
ADP2140 | 2 | 2.3 | 5.5 |
|
|
LT3694 | 3 | 4 | 36 | 2.6 | 1 |
LT3570 | 2 | 2.1 | 36 | 1.5 | 1 |
LT3507 | 4 | 4 | 36 | 1.5, 1.5, 2.4 | 1 |
LTC3100 | 3 | 650m | 5 | 250m | 100m |
LT1939 | 2 | 3 | 25 | 2 | 1 |
LT3500 | 2 | 3 | 36 | 2 | 1 |
LTC3672B-2 | 3 | 2.9 | 5.5 | 500m | 150m, 150m |
LTC3672B-1 | 3 | 2.9 | 5.5 | 500m | 150m, 150m |
LTC3670 | 3 | 2.5 | 5.5 | 500m | 150m, 150m |
LTC3541-2 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3541-3 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3446 | 3 | 2.7 | 5.5 | 1 | 300m, 300m |
LTC3541 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3541-1 | 2 | 2.7 | 5.5 | 500m | 300m |
LTC3445 | 3 | 2.5 | 5.5 | 600m | 50m, 50m |
LT1941 | 3 | 3.3 | 25 | 2, 3 |
|
LTC3700 | 2 | 2.65 | 9.8 | 5 | 150m |
LTC1704 | 2 | 3.15 | 5.5 | 20 | 2 |
