Cypress缓冲器
发布时间：2022-05-24 16:41:07 浏览：1131
Cypress的性能卓越缓冲器（CY2Dx/CY2Cx系列）是一个低抖动、非PLL扇出缓冲器系列，可保证高达1.5GHz的多至10个高频率差分输出（LVPECL、LVDS或CML）。Cypress缓冲器保证行业内最少的额外抖动（0.06ps典型值），而且可以根据CY294x/CY274x器件保证完整的高频率、低抖动时钟树解决方案。
Cypress性能卓越缓冲器保证低抖动和可编程偏移缓冲器。
主要特点
可编程输出偏移
可编程输出乘法器/除法器
提供容错的用户可选冗余参考时钟
Cypress设计人员可以调节输出偏差，并乘除因子以协助适应最后时刻的变动。每台设备的最大灵活性和广泛性的交流检测确保了安全的制作。
Cypress缓冲器在车辆、工业生产、消费和网络行业有广泛性的应用。
深圳市立维创展科技是一家专注代理经销商，主要提供微波功率放大器芯片和进口电源模块产品，代理品牌包含AMCOM、PICO、Cyntec、CUSTOM MMIC、RF-LAMBDA、ADI、QORVO、MA-COM、SOUTHWEST西南微波等，立维创展致力为客户提供高品质、高质量、价格公正的微波元器件产品。
目前，立维创展拥有Cypress品牌，现货库存
CYV15G0203TB-BGXC
CYV15G0101DXB-BBXC
CYV15G0204TRB-BGXC
CYV15G0401DXB-BGXC
CYV15G0104TRB-BGXC
详情了解Cypress品牌请点击：http://www.leadwaytk.com/article/2126.html
Product | Core/IO Operating Voltages (V) | I/O Voltage (V) | Input Frequency min [MHz] | Input Frequency max [MHz] | Operating Temperature min [°C] | Operating Temperature max [°C] | Operating Voltage min [V] | Operating Voltage max [V] | Output Frequency min [MHz] | Output Frequency max [MHz] | Outputs | Peak Reflow Temp [°C] |
CY2309CZXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2302SXI-1T | 3.3/5.0 | 3.3/5.0 | 10 | 133 | -40 | 85 | 3.13 | 5.5 | 10 | 133 | 2 | 260 |
CY2309CZXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2305CSXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2308SXI-4T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2309NZSXC-1HT | 3.3 | 3.3 | 0 | 133 | 0 | 70 | 3 | 3.6 | 0 | 133 | 9 | 260 |
CY2305CSXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY23EP09ZXC-1H | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY23EP05SXI-1 | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2309SXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2305SXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2308SXC-3T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY23EP09ZXI-1HT | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY2304NZZXC-1 | 3.3 | 3.3 | 0 | 140 | 0 | 70 | 3 | 3.6 | 0 | 140 | 4 | 260 |
CY23EP09SXI-1HT | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY2304SXC-2T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2305SXC-1T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY23S05SXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2309CSXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXC-4 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2309CZXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309SXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY23EP05SXI-1T | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2304SXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2308SXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY23EP05SXC-1 | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2300SXCT | 3.3 | 3.3 | 20 | 83.3 | 0 | 70 | 3 | 3.6 | 10 | 166.67 | 4 | 260 |
CY2308SXC-4T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2303SXC | 3.3 | 3.3 | 10 | 41.67 | 0 | 70 | 3 | 3.6 | 10 | 166.67 | 3 | 260 |
CY2309ZXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY23EP05SXC-1HT | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2309CSXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY23S05SXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY23EP09ZXI-1H | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY2305SXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY23EP05SXC-1H | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2309SXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXC-2 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXI-3T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2305CSXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2304NZZXI-1 | 3.3 | 3.3 | 0 | 140 | -40 | 85 | 3 | 3.6 | 0 | 140 | 4 | 260 |
CY23S09SXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309NZSXI-1HT | 3.3 | 3.3 | 0 | 133 | -40 | 85 | 3 | 3.6 | 0 | 133 | 9 | 260 |
CY2305CSXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2304SXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2304SXI-2T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2309NZSXI-1H | 3.3 | 3.3 | 0 | 133 | -40 | 85 | 3 | 3.6 | 0 | 133 | 9 | 260 |
CY23EP09ZXC-1HT | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY2308ZXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308ZXC-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXI-4 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY23S05SXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2309SXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2303SXCT | 3.3 | 3.3 | 10 | 41.67 | 0 | 70 | 3 | 3.6 | 10 | 166.67 | 3 | 260 |
CY2309SXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXC-1T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY23EP09SXI-1H | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 9 | 260 |
CY23EP05SXI-1HT | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2305SXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2309SXC-1T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309NZSXC-1H | 3.3 | 3.3 | 0 | 133 | 0 | 70 | 3 | 3.6 | 0 | 133 | 9 | 260 |
CY2308SXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXC-2T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2302SXC-1T | 3.3/5.0 | 3.3/5.0 | 10 | 133 | 0 | 70 | 3.13 | 5.5 | 10 | 133 | 2 | 260 |
CY2302SXC-1 | 3.3/5.0 | 3.3/5.0 | 10 | 133 | 0 | 70 | 3.13 | 5.5 | 10 | 133 | 2 | 260 |
CY2305CSXC-1 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2302SXI-1 | 3.3/5.0 | 3.3/5.0 | 10 | 133 | -40 | 85 | 3.13 | 5.5 | 10 | 133 | 2 | 260 |
CY2309CZXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2305SXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2305SXI-1 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2300SXC | 3.3 | 3.3 | 20 | 83.3 | 0 | 70 | 3 | 3.6 | 10 | 166.67 | 4 | 260 |
CY2309SXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309CZXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309CZXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309SXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXI-2 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2304NZZXI-1T | 3.3 | 3.3 | 0 | 140 | -40 | 85 | 3 | 3.6 | 0 | 140 | 4 | 260 |
CY2304SXC-2 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2309ZXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309CSXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2304SXC-1T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY2308SXI-3 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXI-2T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2305SXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2305CSXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2308ZXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2308SXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2304NZZXC-1T | 3.3 | 3.3 | 0 | 140 | 0 | 70 | 3 | 3.6 | 0 | 140 | 4 | 260 |
CY2308SXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2309CSXI-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY23S05SXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2305CSXC-1HT | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2305SXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY2308ZXC-1H | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY23EP05SXI-1H | 2.5/3.3 | 2.5/3.3 | 10 | 220 | -40 | 85 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2309ZXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2305CSXC-1T | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 5 | 260 |
CY23EP05SXC-1T | 2.5/3.3 | 2.5/3.3 | 10 | 220 | 0 | 70 | 2.3 | 3.6 | 10 | 220 | 5 | 260 |
CY2304SXI-1T | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 4 | 260 |
CY23S09ZXC-1H | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2309ZXI-1HT | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 9 | 260 |
CY2308SXC-3 | 3.3 | 3.3 | 10 | 133 | 0 | 70 | 3 | 3.6 | 10 | 133 | 8 | 260 |
CY2304SXI-2 | 3.3 | 3.3 | 10 | 133 | -40 | 85 | 3 | 3.6 | 10 | 133 | 4 | 260 |
