ADI低相位噪声放大器
发布时间：2022-02-25 17:19:24 浏览：807
ADI低相位噪声放大器相对于大多数需要高信号完整性的技术应用非常重要。尤其是在仪表仪器、国防科技和电信应用领域。随着振荡器的不断完善，ADI低相位噪声放大器在这些技术应用中显得越来越重要。相位噪声被描述为近载波噪声，通常表现为时钟信号中的抖动。ADI提供多种多样的低相位噪声放大器组合，以满足Lo网络、接收器和发射机的各种规定要求。ADI的产品组合支持各种功率级别和频率，以提供适合特定技术应用的解决方案。
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。大部分产品，均提供现货库存供货。
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
产品型号 | # of Channels | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | Residual Phase Noise (typ) | OIP3 (typ) | Vs+ (min) | Vs+ (max) | Is (typ) |
|
| Hz | Hz | dB | dBc/Hz | dBm | V | V | A |
ADL8150-Die | 1 | 6G | 14G | 13 | -172 | 31.5 | 3 | 6 | 76m |
ADL8150ACPZN | 1 | 6G | 14G | 12 | -172 | 30 | 3 | 6 | 74m |
ADPA9002 | 1 | 0 | 10G | 15.5 |
| 40.5 | 10 | 15 | 385m |
HMC8411 |
| 10M | 10G | 15 |
| 34 |
|
| 55m |
HMC8411-EP |
| 10M | 10G | 15 |
| 34 |
|
| 55m |
HMC8412-Die | 1 | 400M | 10G | 15 |
| 32 | 3 | 6 | 60m |
HMC8412LP2FE | 1 | 400M | 11G | 15 |
| 33 |
| 6 | 60m |
HMC998A-Die | 1 | 0 | 22G | 14.5 |
| 43 | 11 | 15 | 500m |
HMC998ALP5E | 1 | 0.1G | 20G | 11 |
| 41 | 11 | 15 | 500m |
HMC998APM5E | 1 | 0 | 22G | 15 |
| 42 | 11 | 15 | 500m |
HMC907A-Die | 1 | 200M | 22G | 13.5 |
| 41 | 8 | 11 | 350m |
HMC907ALP5E | 1 | 200M | 22G | 13 |
| 40 | 8 | 11 | 350m |
HMC907APM5E | 1 | 200M | 22G | 13 |
| 40 | 8 | 11 | 350m |
HMC797A-Die | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC797ALP5E | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC797APM5E | 1 | 0 | 22G | 15 | -161 | 41 | 8 | 11 | 400m |
HMC5805A | 1 | 0 | 40G | 11.5 |
| 29 | 10 | 12 | 175m |
HMC589A | 1 | 0 | 4G | 21 | -172 | 32 |
|
| 82m |
HMC930A-Die | 1 | 0 | 40G | 13 |
| 33.5 |
|
| 175m |
HMC788A | 1 | 10M | 10G | 14 | -153 | 33 | 4.5 | 5.5 | 76m |
ADL5611 | 1 | 30M | 6G | 22.2 | -156 | 40 | 4.75 | 5.25 | 91m |
ADL5544 | 1 | 30M | 6G | 17.4 | -156 | 34.9 | 4.75 | 5.25 | 55m |
ADL5602 | 1 | 50M | 4G | 19.3 | -162 | 42 | 4.5 | 5.5 | 89m |
ADL5521 | 1 | 400M | 4G | 20.8 |
| 37 | 3 | 5 | 60m |
HMC606-Die | 1 | 2G | 18G | 12.5 | -166 | 22 |
|
| 64m |
HMC606LC5 | 1 | 2G | 18G | 12.5 | -166 | 22 |
|
| 64m |
HMC3653 | 1 | 7G | 15G | 15 | -160 | 28 |
| 6 | 44m |
HMC460-Die | 1 | 0G | 20G | 14 | -155 | 28 |
|
| 75m |
HMC460LC5 | 1 | 0 | 20G | 14 | -155 | 29 |
| 8 | 75m |
HMC519-Die | 1 | 18G | 32G | 15 | -150 | 26 |
|
| 75m |
HMC519LC4 | 1 | 18G | 31G | 14.4 | -150 | 23 |
| 3 | 75m |
HMC311LP3 | 1 | 0M | 6G | 14.5 | -165 | 32 | 4.5 | 5.5 | 55m |
HMC311SC70 | 1 | 0M | 8G | 15 | -165 | 30 | 4.5 | 5.5 | 55m |
HMC311ST89 | 1 | 0M | 6G | 15 | -165 | 27 | 4.5 | 5.5 | 55m |
HMC326 | 1 | 3G | 4.5G | 21 | -167 | 36 |
| 5 | 130m |
