Anaren射频微波TTM 的巴伦变压器
发布时间：2021-12-22 17:04:50 浏览：1513
Anaren射频微波巴伦变压器提供抗阻转换，并将不平衡抗阻转换为平衡抗阻，反之亦然。Anaren射频微波巴伦外型精巧，占用面积小，性能高于传统式陶瓷和集总元件巴伦。除此之外，Anaren射频微波所有的巴伦变压器都遵循RoHS标准规定。Anaren射频微波TTM 的巴伦变压器主要用于电视卫星、无线基础设施和其它消费电子应用。Anaren射频微波TTM的巴伦变压器还通过100%射频测试，并且以卷带模式运输，以便于轻松集成到拾放、大批量生产制造环境中。
深圳市立维创展科技是Anaren品牌的经销商，主要提供贴片混合耦合器、巴伦变压器、延迟线、定向耦合器、Doherty合路器、功分器、微蜂窝型耦合器、 RF Crossovers产品，产品原装库存，极具价格优势，欢迎咨询
详情了解Anaren请点击：http://www.leadwaytk.com/brand/11.html
或联系我们的销售工程师：0755-83642657 QQ: 2295048674
零件号 | 频率 | power | 不平衡端口阻抗 | 平衡端口阻抗 | 回波损耗 | 插入损耗 | 幅度平衡 | 相位平衡 |
| GHz | W | Ω | Ω | D b | D b | D b | Degrees |
B0205F50200AHF | 0.2 - 0.5 | 2 | 50 | 200 | 13.9 | 1.6 | 0.4 | 180 +/- 3.1 |
BD0205F5050AHF | 0.2 - 0.5 | 2 | 50 | 50 | 11 | 1.1 | 0.6 | 180 +/- 3 |
B0225J7575AHF | 0.2 - 2.5 | 0.5 | 75 | 75 | 14 | 1.1 | 3.2 | 180 +/- 1.3 |
B0310J50100AHF | 0.3 - 1.0 | 2 | 50 | 100 | 8.1 | 1 | 2.8 | 180 +/- 36 |
B0322J5050AHF | 0.3 - 2.2 | 2 | 50 | 50 | 12.2 | 1.6 | 1.3 | 180 +/- 21 |
B0430J50100AHF | 0.4 - 3.0 | 1 | 50 | 100 | 8.4 | 4 | 1.4 | 180 +/- 7 |
X4B10L1-5050G | 0.6 - 2.5 | 1 | 50 | 50 | 20 | 1 | 1.5 | 180 +/- 15 |
X4BD10L1-50100G | 0.6 - 2.5 | 1 | 50 | 100 | 10 | 1.8 | 1.4 | 180 +/- 4 |
X4BD10L1-50200G | 0.6 - 2.5 | 1 | 50 | 200 | 10 | 1.9 | 1.9 | 180 +/- 9 |
XT0010E15012S | 0.06-0.9 | 80 | 50 | 50 | 15.0 | 0.40 | 不适用 | 不适用 |
T0727J5012AHF | 0.7 - 2.7 | 1 | 50 | 12.5 | 15 | 0.9 | 不适用 | 不适用 |
3A412 | 0.8 - 1.0 | 250 | 50 | 12.5 | 15 | 0.48 | 0.4 | 180 +/- 5 |
3A412S | 0.8 - 1.0 | 250 | 50 | 12.5 | 15 | 0.48 | 0.4 | 180 +/- 5 |
BD0810J50100AHF | 0.8 - 1.0 | 2 | 50 | 100 | 13 | 0.95 | 0.4 | 180 +/- 2 |
BD0810J50150AHF | 0.8 - 1.0 | 2 | 50 | 150 | 13.3 | 1.1 | 0.6 | 180 +/- 6 |
BD0810J50200AHF | 0.8 - 1.0 | 2 | 50 | 200 | 14.5 | 1 | 1.1 | 180 +/- 8 |
BD0810N50100AHF | 0.8 - 1.0 | 0.75 | 50 | 100 | 18 | 1.2 | 1.4 | 180 +/- 9 |
BD0826J50200AHF | 0.8 - 2.6 | 2 | 50 | 200 | 8.5 | 1.5 | 1.3 | 180 +/- 7 |
BD0922J75100AHF | 0.9 - 2.2 | 2 | 75 | 100 | 9.1 | 1.64 | 0.8 | 180 +/- 2.66 |
3A325 | 0.47 - 0.86 | 275 | 50 | 25 | 10 | 0.35 | 0.4 | 180 +/- 5 |
B0110E50200AHF | 0.085 - 1.300 | 0.5 | 50 | 200 | 11 | 1.5 | 0.8 | 180 +/-4 |
B0922J7575A50HF | 0.95 - 2.15 | 2 | 75 | 75 | 12 | 1.1 | 1.4 | 180 +/- 3 |
B0922J7575AHF | 0.95 - 2.15 | 2 | 75 | 75 | 7 | 1.2 | 1.4 | 180 +/- 3 |
B0922N7575AHF | 0.95 - 2.15 | 0.75 | 75 | 75 | 13.2 | 0.76 | 2.1 | 180 +/- 18.39 |
B0809J50ATI | 0.850 - 0.915 | 2 | 50 | 匹配 | 15.3 | 0.6 | 不适用 | 不适用 |
BD1222J50200AHF | 1.2 - 2.2 | 2 | 50 | 200 | 14 | 0.6 | 0.9 | 180 +/- 6 |
X4BD20L1-50200G | 1.2 - 2.7 | 1 | 50 | 200 | 14 | 0.95 | 1.5 | 180 +/- 7 |
X4BD20L1-50100G | 1.2 - 2.7 | 1 | 50 | 100 | 14 | 0.7 | 2 | 180 +/- 5 |
X4B20L1-5050G | 1.2 - 2.7 | 1 | 50 | 50 | 20 | 0.8 | 0.9 | 180 +/- 7 |
BD1416N50100AHF | 1.4 - 1.6 | 0.75 | 50 | 100 | 14 | 0.9 | 1.2 | 180 +/- 9 |
BD1631J50100AHF | 1.6 - 3.1 | 2 | 50 | 100 | 10 | 1 | 1 | 180 +/- 5 |
BD1722J50100AHF | 1.7 - 2.2 | 2 | 50 | 100 | 12 | 1.2 | 1.2 | 180 +/- 6 |
BD1722J50200AHF | 1.7 - 2.2 | 2 | 50 | 200 | 15 | 0.7 | 0.9 | 180 +/- 8 |
BD1722N5050AHF | 1.7 - 2.2 | 0.75 | 50 | 50 | 13 | 1.1 | 0.8 | 180 +/- 7 |
3W525S | 1.8 - 2.5 | 150 | 50 | 25 | 15 | 0.38 | 0.4 | 180 +/- 5 |
BD2040J50100AHF | 2.0 - 4.0 | 2 | 50 | 100 | 14.2 | 1.1 | 1.48 | 180 +/- 15 |
BD2130J5050AHF | 2.1 - 3.0 | 2 | 50 | 50 | 10 | 1.2 | 1 | 180 +/- 5 |
BD2239N5050AHF | 2.2 - 3.9 | 1 | 50 | 50 | 8 | 1.6 | 1.4 | 180 +/- 8 |
BD2326L50200AHF | 2.3 - 2.6 | 2 | 50 | 200 | 12 | 1.1 | 0.8 | 180 +/- 9 |
BD2326L50150AHF | 2.3 - 2.6 | 2 | 50 | 150 | 12.0 | 1.10 | 0.50 | 180 +/- 4 |
BD2327N50100AHF | 2.3 - 2.7 | 1 | 50 | 100 | 17 | 0.8 | 1 | 180 +/- 7 |
X4B40L1-5050G | 2.3 - 3.5 | 1 | 50 | 50 | 18 | 0.55 | 0.8 | 180 +/- 6 |
X4BD40L1-50100G | 2.3 - 6.0 | 1 | 50 | 100 | 13.5 | 1 | 1.5 | 180 +/- 3 |
X4BD40L1-50200G | 2.3 - 6.0 | 1 | 50 | 200 | 12 | 0.9 | 1.15 | 180 +/- 8 |
X4BD40L1-5050G | 2.3 - 6.0 | 1 | 50 | 50 | 8.5 | 1.1 | 0.96 | 180 +/- 3 |
BD2425J50200AHF | 2.4 - 2.5 | 2 | 50 | 200 | 9.5 | 0.8 | 0.5 | 180 +/- 6 |
BD2425N100ATI | 2.4 - 2.5 | 1 | 50 | 匹配 | 17.3 | 0.8 | 不适用 | 不适用 |
BD2425N50100AHF | 2.4 - 2.5 | 1 | 50 | 100 | 18 | 0.7 | 0.6 | 180 +/- 3 |
BD2425N50200AHF | 2.4 - 2.5 | 1 | 50 | 200 | 21 | 0.7 | 1 | 180 +/- 6 |
BD2425N5050AHF | 2.4 - 2.5 | 0.75 | 50 | 50 | 15 | 0.9 | 0.9 | 180 +/- 7 |
BD2425N5075AHF | 2.4 - 2.5 | 1 | 50 | 75 | 14 | 0.9 | 0.9 | 180 +/- 3 |
BD2425N50ATI | 2.4 - 2.5 | 1 | 50 | 匹配 | 13 | 0.6 | 不适用 | 不适用 |
BD2425NCSR | 2.4 - 2.5 | 1 | 50 | 匹配 | 10 | 1 | 0.5 | 180 +/- 4 |
BD2425NNRF | 2.4 - 2.5 | 1 | 50 | 匹配 | 10.2 | 1.25 | 不适用 | 不适用 |
BD2425P50100AHF | 2.4 - 2.5 | 1 | 50 | 100 | 19 | 0.9 | 1.5 | 180 +/- 9 |
BD2425P5075AHF | 2.4 - 2.5 | 1 | 50 | 75 | 11 | 1.15 | 1.56 | 180 +/- 6 |
BD2425J50100AHF | 2.4 - 2.5 | 2 | 50 | 100 | 14 | 0.75 | 0.5 | 180 +/- 5 |
BD2635L5050AHF | 2.6-3.5 | 2 | 50 | 50 | 18.0 | 0.60 | 0.70 | 180 +/- 4 |
BD2635L50100AHF | 2.6-5.0 | 2 | 50 | 100 |
| 0.60 | 0.50 | 180 +/- 3 |
BD3150L50100AHF | 3.1 - 5.0 | 2 | 50 | 100 | 9.5 | 1.1 | 0.9 | 180 +/- 9 |
BD3150N50100AHF | 3.1 - 5.0 | 1 | 50 | 100 | 16 | 0.7 | 1.3 | 180 +/- 7 |
BD3238N5050AHF | 3.2 - 3.8 | 1 | 50 | 50 | 7 | 1 | 1.5 | 180 +/- 6 |
BD3438J50200AHF | 3.4 - 3.8 | 2 | 50 | 200 | 11 | 1 | 0.6 | 180 +/- 10 |
BD4859N50100AHF | 4.8 - 5.9 | 1 | 50 | 100 | 15 | 0.6 | 1.5 | 180 +/- 8 |
BD4859N50150AHF | 4.8 - 5.9 | 1 | 50 | 150 | 12 | 0.6 | 1.4 | 180 +/- 10 |
BD4859N5050AHF | 4.8 - 5.9 | 1 | 50 | 50 | 13 | 0.7 | 1.2 | 180 +/- 7 |
BD60120N50100AHF | 5.9 - 11.7 | 1 | 50 | 100 | 14 | 0.9 | 1.6 | 180 +/- 13 |
BD120170N50100AHF | 12.7 - 15.4 | 1 | 50 | 100 | 13.9 | 0.53 | 1.2 | 180 +/- 20 |
BD170240N50100AHF | 17.7 - 23.6 | 1 | 50 | 100 | 16 | 1 | 1 | 180 +/- 20 |
