ADI低功耗运算放大器（≤ 1mA/放大器）
发布时间：2021-10-21 16:53:41 浏览：1583
ADI低功耗运算放大器能够在大多数应用中提供多种多样的优势，如提高电池使用寿命、优化终端设备的散热安全管理、减少自发热以尽可能减少热相关的失调漂移，及其减少操作系统总功能损耗和成本费用等。ADI低功耗运算放大器提供高功效元器件，同时又不放弃速度、噪声性能和精密度，一直是ADI公司产品研发的重要原则。
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。
大部分产品，均提供现货库存供货。
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
或联系ADI的销售工程师： 0755-83642657 QQ: 2295048674
产品型号 | GBP (typ) | Slew Rate (typ) | Ibias (max) | Iq/Amp (typ) | Vos (max) | VNoise Density (typ) | 0.1 to 10 Hz VNoise (typ) | Shutdown | Vs span (min) | Vs span (max) |
| Hz | V/us | A | A | V | V/rtHz | V p-p |
| V | V |
ADA4097-1 | 130k | 100m | 300p | 32.5µ | 60µ | 53n | 1µ | Yes | 3 | 50 |
ADA4098-1 | 1.05M | 400m | 700p | 162.5µ | 15µ | 18n | 400n | Yes | 3 | 55 |
LTC2068 | 100k | 17.5m | 35p | 7.5µ | 5µ | 80n | 1.7µ | Yes | 1.7 | 5.25 |
LTC2065 | 20k | 3.5m | 20p | 1.4µ | 5µ | 220n | 4.6µ | Yes | 1.7 | 5.25 |
LTC2050HV | 3M | 2 | 75p | 800µ | 3µ |
| 1.5µ | Yes | 2.7 | 11 |
LTC2064 | 20k | 3.5m | 20p | 1.4µ | 5µ | 220n | 4.6µ | Yes | 1.7 | 5.25 |
LTC2067 | 100k | 17.5m | 35p | 7.5µ | 5µ | 80n | 1.7µ | Yes | 1.7 | 5.25 |
ADA4505-1 | 50k | 6m | 2p | 9µ | 3m | 65n | 2.95µ | No | 1.8 | 5 |
ADA4622-4 | 8M | 23 | 10p | 665µ | 350µ | 12.5n | 750n | No | 5 | 30 |
ADA4622-1 | 8M | 23 | 10p | 715µ | 350µ | 12.5n | 750n | Yes | 5 | 30 |
LTC2063 | 20k | 3.5m | 20p | 1.4µ | 5µ | 220n | 4.6µ | Yes | 1.7 | 5.25 |
LTC6258 | 1.3M | 240m | 75n | 20µ | 400µ | 38n | 2µ | Yes | 1.8 | 5.25 |
LTC6259 | 1.3M | 240m | 75n | 20µ | 400µ | 38n | 2µ | Yes | 1.8 | 5.25 |
LTC6260 | 1.3M | 240m | 75n | 20µ | 400µ | 38n | 2µ | No | 1.8 | 5.25 |
LTC6261 | 30M | 7 | 100n | 245µ | 400µ | 13n | 1.25µ | Yes | 1.8 | 5.25 |
LTC6262 | 30M | 7 | 100n | 245µ | 400µ | 13n | 1.25µ | Yes | 1.8 | 5.25 |
LTC6263 | 30M | 7 | 750n | 245µ | 400µ | 13n | 1.25µ | Yes | 1.8 | 5.25 |
LTC2066 | 100k | 17.5m | 35p | 7.5µ | 5µ | 80n | 1.7µ | Yes | 1.7 | 5.25 |
ADA4522-1 | 2.7M | 1.7 | 150p | 840µ | 5µ | 5.8n | 117n | Yes | 4.5 | 55 |
ADA4522-4 | 2.7M | 1.7 | 150p | 830µ | 5µ | 5.8n | 117n | No | 4.5 | 55 |
ADA4530-1 | 2M | 1.4 | 20f | 900µ | 40µ | 14n | 4µ | No | 4.5 | 16 |
ADA4622-2 | 8M | 23 | 10p | 665µ | 350µ | 12.5n | 0.75µ | No | 5 | 30 |
ADA4806-1 | 30M | 160 | 800n | 570µ | 125µ | 5.2n |
| Yes | 3 | 10 |
ADA4807-4 | 200M | 225 | 1.6µ | 1m | 175µ | 3.3n | 160n | No | 2.7 | 11 |
ADA4522-2 | 2.7M | 1.7 | 150p | 830µ | 5µ | 5.8n | 117n | No | 4.5 | 55 |
ADA4084-2S |
|
| 300n |
| 100µ |
|
| No | 3 | 30 |
ADA4177-1 | 3.5M | 1.5 | 1n | 500µ | 60µ | 8n | 175n | No | 10 | 30 |
ADA4807-2 | 200M | 225 | 1.6µ | 1m | 125µ | 3.3n | 160n | Yes | 2.7 | 11 |
LT6023 | 40k | 1.45 | 3n | 18µ | 30µ | 132n |
| No | 3 | 30 |
LT6023-1 | 40k | 1.45 | 3n | 18µ | 30µ | 132n |
| Yes | 3 | 30 |
ADA4177-4 | 3.5M | 1.5 | 1n | 500µ | 60µ | 8n | 175n | No | 10 | 30 |
ADA4807-1 | 200M | 225 | 1.6µ | 1m | 125µ | 3.3n | 160n | Yes | 2.7 | 11 |
ADA4177-2 | 3.5M | 1.5 | 1n | 500µ | 60µ | 8n | 175n | No | 10 | 30 |
ADA4805-2 | 30M | 190 | 800n | 570µ | 125µ | 5.2n | 300n | Yes | 2.7 | 10 |
ADA4084-1 | 15.9M | 4.6 | 250n | 565µ | 100µ | 3.9n | 100n | No | 3 | 30 |
ADA4805-1 | 30M | 190 | 800n | 570µ | 125µ | 5.2n | 300n | Yes | 2.7 | 10 |
LT6020 | 400k | 5 | 1n | 90µ | 30µ | 50n | 1.1µ | No | 3 | 30 |
LT6020-1 | 400k | 5 | 1n | 90µ | 30µ | 50n | 1.1µ | Yes | 3 | 30 |
ADA4077-1 | 3.9M | 1 | 1n | 400µ | 35µ | 7n | 250n | No | 5 | 30 |
ADA4084-4 | 15.9M | 4.6 | 250n | 565µ | 100µ | 3.9n | 100n | No | 3 | 30 |
AD8244 |
| 800m | 3p | 180µ | 350µ | 13n | 400n | No | 3 | 36 |
ADA4077-4 | 3.9M | 1 | 1n | 400µ | 50µ | 7n | 250n | No | 5 | 30 |
ADA4661-2 | 4M | 2.2 | 15p | 630µ | 150µ | 18n | 3µ | No | 3 | 18 |
ADA4666-2 | 4M | 2 | 15p | 630µ | 2.2m | 18n | 3µ | No | 3 | 18 |
LT6015 | 3.2M | 750m | 5n | 315µ | 50µ | 18n | 500n | No | 3 | 50 |
LTC2057 | 1.5M | 1.2 | 200p | 800µ | 4µ | 11n | 200n | Yes | 4.75 | 36 |
LTC2057HV | 1.5M | 1.2 | 200p | 800µ | 4µ | 11n | 200n | Yes | 4.75 | 60 |
ADA4096-2S | 783k |
| 25n |
| 300µ | 27n | 700n | No | 3 | 30 |
LT6016 | 3.2M | 750m | 5n | 315µ | 50µ | 18n | 500n | No | 3 | 50 |
LT6017 | 3.2M | 750m | 5n | 315µ | 50µ | 18n | 500n | No | 3 | 50 |
ADA4077-2 | 3.9M | 1 | 1n | 400µ | 35µ | 7n | 250n | No | 5 | 30 |
AD8659 | 230k | 80m | 20p | 22µ | 350µ | 45n | 5µ | No | 2.7 | 18 |
ADA4096-4 | 786k | 400m | 25n | 60µ | 300µ | 27n | 700n | No | 3 | 30 |
ADA4084-2 | 15.9M | 4.6 | 250n | 565µ | 100µ | 3.9n | 100n | No | 3 | 30 |
ADA4638-1 | 1.5M | 1.5 | 90p | 850µ | 4.5µ | 66n | 1.2µ | No | 4.5 | 30 |
ADA4096-2 | 786k | 400m | 25n | 60µ | 300µ | 27n | 700n | No | 3 | 30 |
AD8657 | 230k | 80m | 20p | 22µ | 350µ | 45n | 5µ | No | 2.7 | 18 |
ADA4092-4 | 1.4M | 400m | 80n | 165µ | 1.5m | 24n | 800n | No | 2.7 | 36 |
