ADI低噪声放大器
发布时间：2021-04-16 15:20:14 浏览：1479
ADI低噪声放大器能够 覆盖从直流电压(IF)到射频微波和W波段(95GHz)的频率使用范围。这种依托于MMIC的设计涵盖了各种各样增益值和带宽，噪声系数低至0.7dB。ADI的低噪声放大器提供了行业内现有的最低噪声和最高线性度。许多设计提供内部结构匹配至50Ω的自偏置拓扑。ADI低噪声放大器可广泛运用于电信、仪器设备和军事/航空航天行业领域。所有的ADI低噪声放大器在整个频率、工作温度和电源电压使用范围内都提供额定性能指标。
深圳市立维创展科技是ADI的分销商，主要供应放大器、线性产品、数据转换器、音视频产品、宽带产品、时钟和定时IC、光纤通信产品、接口和间隔、MEMS和传感器、电源和热经管、处理器和DSP、射频和图形处理器、开关和分配器等。
大部分产品，均提供现货库存供货。
*部分型号需申请出口许可
详情了解ADI芯片请点击：http://www.leadwaytk.com/brand/25.html
或联系我们的销售工程师： 0755- 83642657 QQ： 2295048674
*详情了解更多ADI芯片请联系我们的销售工程师。
产品型号 | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | OP1dB (typ) | OIP3 (typ) | NF (typ) | Vs (typ) | Is (typ) |
| Hz | Hz | dB | dBm | dBm | dB | V | A |
ADCA3950 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADL8104 | 400M | 7.5G | 15 | 20 | 32 | 3.5 | 5 | 150m |
ADCA3952 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
HMC8412-Die | 400M | 10G | 15 | 19 | 32 | 1.5 | 5 | 60m |
HMC8412LP2FE | 400M | 11G | 15 | 18 | 33 | 1.5 | 5 | 60m |
ADL9005 | 10M | 26.5G | 18.5 | 13.5 | 25 | 2.5 | 5 | 80m |
ADL9006-Die | 2G | 28G | 15.5 | 17 | 21 | 2.5 | 5 | 55 |
ADL9006ACGZN | 2G | 28G | 15.5 | 18 | 23 | 2.5 | 5 | 53m |
ADH519S | 17.5G | 31.5G | 11 | 7.2 | 17.2 | 4 | 3 | 95m |
ADL8111 | 10M | 8G | 12.5 | 19.5 | 34 | 2.8 | 5 | 70m |
HMC8411 | 10M | 10G | 15 | 20 | 34 | 1.7 | 5 | 55m |
ADCA3990 | 45M | 1.218G | 24.5 |
|
| 4 | 34 | 535m |
ADCA3992 | 45M | 1.218G | 26 |
|
| 4 | 34 | 535m |
ADL7003 | 50G | 95G | 14 | 14 | 21 | 5.5 | 3 | 120m |
HMC8325 | 71G | 86G | 21 | 13 | 22 | 3.6 | 3 | 50m |
HMC392A-Die | 3.5G | 7G | 17.2 | 19 | 32.5 | 1.7 | 5 | 59m |
HMC392ALC4 | 3.5G | 8G | 17 | 19 | 34.5 | 1.8 | 5 | 61m |
HMC7950 | 2G | 28G | 15 | 16 | 26 | 2 | 5 | 64m |
HMC717A | 4.8G | 6G | 14.5 | 18 | 29.5 | 1.3 | 5 | 73m |
HMC8401-Die | 10M | 28G | 14.5 | 16.5 | 26 | 1.5 | 7.5 | 60m |
HMC8402-Die | 2G | 30G | 13.5 | 20 | 24 | 2.5 | 7 | 68m |
HMC8410-Die | 10M | 10G | 18 | 20.5 | 31.5 | 1.4 | 5 | 65m |
HMC8410LP2FE | 10M | 10G | 18 | 21 | 31.5 | 1.4 | 5 | 65m |
ADL5721 | 5.9G | 8.5G | 25.9 | -9.3 | 4 | 1.6 | 3.3 | 86.5m |
ADL5723 | 10.1G | 11.7G | 24.5 | -10 | 2.2 | 2.2 | 3.3 | 109.1m |
ADL5724 | 12.7G | 15.4G | 26.4 | -11 | 2 | 2.1 | 3.3 | 109.7m |
ADL5725 | 17.7G | 19.7G | 27.8 | -14 | -1.5 | 2.4 | 3.3 | 108m |
ADL5726 | 21.2G | 23.6G | 24.7 | -9.5 | 1 | 3.3 | 3.3 | 92.4m |
HMC8400-Die | 2G | 30G | 14 | 14.5 | 25 | 2 | 5 | 67m |
ADA8282 | 0 | 42.3M | 18 |
|
|
| 3.3 | 19.6m |
HMC1127 | 2G | 50G | 14 | 12 | 22 | 6 | 5 | 65m |
HMC1126 | 2G | 50G | 11 | 16 | 28 | 4 | 5 | 66m |
HMC1049-Die | 0.3G | 20G | 16 | 13 | 25 | 2 | 7 | 70m |
HMC1049LP5E | 0.3G | 20G | 15 | 14.5 | 29 | 1.8 | 7 | 70m |
HMC1040-Die | 20G | 44G | 21 | 14 | 25.5 | 2.5 | 2.5 | 65m |
HMC1040LP3CE | 24G | 43.5G | 20 | 12 | 24 | 2.7 |
| 70m |
HMC902-Die | 5G | 11G | 20 | 16 | 28 | 1.6 | 3.5 | 80m |
HMC902LP3E | 5G | 11G | 19 | 16 | 28 | 1.8 | 3.5 | 80m |
