LINEAR电池备用 IC

发布时间：2021-03-05 17:06:08 浏览：2079

LINEAR电源一系列监控电路是单片机的完整解决方案，可以实现微机系统的电源监控和电池控制功能。这些功能包括微处理器复位、备用电池切换、定时器、CMOS ram写保护和电源故障警告。

应用领域：

关键微处理器监控

控制器

智能仪表

汽车系统

便携式仪表

深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。

详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html

或联系我们的销售工程师：0755-83642657 QQ: 2295048674


产品型号	Vin (min)	Vin (max)	Comments	Package
	V	V
LT8228	6	100	Bidirectional Synchronous 100V Buck/Boost Controller with Reverse Supply, Reverse Current and Fault Protection	38-Lead TSSOP w/ EP
LT8708	2.8	80	80V Synchronous 4-Switch Buck-Boost DC/DC Controller with Flexible Bidirectional Capability	40-Lead QFN (5mm x 8mm x 0.75mm w/ EP),64-Lead LQFP (10mm x 10mm w/ EP)
LT8708-1	2.8	80	80V Synchronous 4-Switch Buck-Boost DC/DC Controller with Flexible Bidirectional Capability	40-Lead QFN (5mm x 8mm x 0.75mm w/ EP),64-Lead LQFP (10mm x 10mm w/ EP)
LTC4091	6	36	36V Battery Charger and Power Backup Manager	22-Lead DFN (6mm x 3mm w/ EP)
LTC4040	3.5	5.5	2.5A Battery Backup Power Manager	24-Lead QFN (4mm x 5mm x 0.75mm w/ EP)
LTC4110	4.5	19	Battery Backup System Manager	38-Lead QFN (5mm x 7mm w/ EP)
