LINEAR电源的专用的恒定电流源产品类别提供了应用和设计的简单性；电压、电流和热保护功能模块；及其内嵌电流限定。LINEAR恒定电流源可选用数个标准模拟构件设计制作，包含运算放大器、LED驱动器和电池充电器。

深圳市立维创展科技是ADI \ LINEAR的代理商，以代理分销库存现货ADI \ LINEAR为产品优势，可提供当日发货服务，欢迎咨询。

详情了解LINEAR电源模块请点击：http://www.leadwaytk.com/brand/19.html

或联系我们的销售工程师：0755-83050846 QQ: 3312069749

产品型号	Vin (min)	Vin (max)	Output Current Range	Isupply (typ)	Features	Current Sources Initial Accuracy
	V	V		A		%
LTM8042	3	30	35mA to 1000mA	4.2m	Constant Current Constant Voltage
LTM8042-1	3	30	35mA to 350mA	4.2m	Constant Current Constant Voltage
LT3083	1.2	23	1mA to 3A	350µ	Current Source Reference
LT3082	1.2	40	0.5mA to 200mA	300µ	Current Source Reference
LT3092	1.2	40	0.5mA to 200mA	300µ	Current Limiting, Reverse Current Protection, Reverse Input Protection, Thermal Protection	1
LTM8040	4	36	35mA to 1000mA	2.6m	Constant Current Constant Voltage, Output Current Limit
LT3085	1.2	36	0.5mA to 500mA	300µ	Current Source Reference	1
LT3080-1	1.2	36	0.5mA to 1100mA	300µ	Current Source Reference	1
LT3080	1.2	36	0.5mA to 1000mA	300µ	Current Source Reference	1
ADN8810	3	5.5	0mA to 300mA	4m	Laser Driver
LM334S	800m	30	1uA to 10mA	280µ	Reverse Current Protection	3
